Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 1800 x 760 mm | |
|---|---|---|
| main work surface depth | 900 mm | |
| return cabinet width | 1200 mm | |
| desktop thickness | 50 mm | |
| edge band thickness | 2 mm | |
| knee clearance height | 680 mm | |
| knee clearance width | 1600 mm | |
| cantilever leg wall thickness | 3 mm | |
| cable grommet diameter | 80 mm | |
| curved return radius | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 150 kg | |
|---|---|---|
| drawer slide load rating | 45 kg | |
| drawer slide cycle rating | 50000 cycles | |
| cabinet hinge cycle rating | 80000 cycles | |
| surface scratch resistance | 2000 revolutions | |
| product net weight | 82 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop substrate | E0-grade engineered wood board | |
|---|---|---|
| desktop finish | Scratch-resistant matte laminate | |
| base cabinet construction | 18mm thick MDF with off-white matte lacquer | |
| cantilever support leg | 3mm thick powder-coated steel | |
| accent trim | 10mm wide matte blue PVC edge trim | |
| drawer hardware | Cold-rolled steel soft-close full-extension slides | |
| modesty panel | 12mm thick painted MDF with geometric framed design | |
| cabinet base trim | Brushed stainless steel kick plate | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| storage configuration | 2 file drawers, 1 open storage cubby, 1 lockable cabinet compartment | |
|---|---|---|
| cable management | 2 desktop cable grommets and under-desk steel cable tray | |
| drawer operation | Recessed finger-pull design with soft-close damping | |
| height configuration | Fixed 760mm work surface height | |
| edge design | Rounded polished impact-resistant edges on all work surfaces | |
| lock system | Central lock for all storage drawers and cabinet doors | |
| support structure | Cantilever leg design with full open knee space | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| executive private office | Sized for CEO, general manager or director private workspaces | |
|---|---|---|
| high-end commercial office | Contemporary luxury styling fits premium Grade A office interiors | |
| home executive office | Configurable for high-end residential work-from-home setups | |
| boardroom ancillary space | Can be used as a meeting support desk outside boardrooms | |
| recommended pairing | Match with high-back executive leather office chair and wall-mounted display cabinet |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance test standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 10357.1-2013 | Desk mechanical performance test methods |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 3. GB/T 10357.1-2013: Desk mechanical performance test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
