Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk + side return) | 2400 x 2050 x 760 mm | |
|---|---|---|
| Main worktop thickness | 50 mm | |
| Pedestal cabinet height | 660 mm | |
| Central knee clearance width | 1200 mm | |
| Knee clearance height under worktop | 600 mm | |
| Side return worktop depth | 600 mm | |
| Edge banding thickness | 2 mm | |
| Modesty panel height | 400 mm | |
| Integrated LED strip length (front modesty) | 1180 mm | |
| Pedestal cabinet internal drawer height | 180 mm | |
| Cable grommet diameter | 80 mm | |
| Floor clearance under pedestal bases | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 200 kg | |
|---|---|---|
| Drawer slide rated load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Hinge cycle rating for cabinet doors | 80000 open/close cycles | |
| Desk net weight (assembled) | 180 kg | |
| Recommended maximum user weight for seating compatibility | 150 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Standard warranty period for structural components | 60 months | |
| Available finish color options | 60 | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop substrate | 25mm thick E0-grade engineered wood | |
|---|---|---|
| Pedestal base panels | 18mm thick MDF with matte cream lacquer finish | |
| Edge protection | 2mm thick impact-resistant PVC edge banding | |
| Structural support frame | 1.5mm thick powder-coated square steel internal beams | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Cabinet door hinges | Cold-rolled steel soft-close concealed hinges | |
| Integrated lighting | 3000K warm white SMD LED strip with diffuser cover | |
| Cable management components | ABS plastic grommets and steel wire cable tray | |
| Leveling feet | Reinforced nylon adjustable glides | |
| Surface finish coating | Scratch-resistant melamine veneer on worktop | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Integrated LED ambient lighting | Warm white strip controlled by concealed touch switch | |
|---|---|---|
| Left pedestal storage | 1 lockable file drawer + 2 stationery drawers with soft-close slides | |
| Right pedestal storage | 1 lockable cabinet door with adjustable internal shelf | |
| Cable management system | 2 desk-top grommets + under-desk cable tray | |
| Side return work surface | Extended auxiliary surface for printer, documents or guest-facing placement | |
| Adjustable leveling feet | 10mm vertical adjustment per foot | |
| Modesty panel privacy screen | Solid front panel spanning central knee opening | |
| Lockable storage system | Centralized key lock for all pedestal drawers and doors | |
| Return configuration compatibility | Supports left or right side return installation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary application for CEO, director or senior manager daily work | |
|---|---|---|
| High-end corporate meeting room for small leadership discussions | Provides sufficient surface space for documents and meeting materials | |
| Luxury home office for remote executive work | Blends modern residential styling with commercial office functionality |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to commercial desk design | |
|---|---|---|
| EN 13722:2004 | Office furniture storage cabinets performance requirements, applicable to pedestal cabinets |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to pedestal drawer and door cycles |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction and finish | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0-grade substrate verification | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to worktop and cabinet panel materials | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to static load and stability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction and finish; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0-grade substrate verification; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to worktop and cabinet panel materials; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to static load and stability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
