Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main + return) | 2400 x 1800 x 1220 mm | |
|---|---|---|
| Minimum seated work surface height | 750 mm | |
| Maximum standing work surface height | 1220 mm | |
| Main worktop depth | 800 mm | |
| Side return worktop depth | 600 mm | |
| Worktop panel thickness | 64 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance width (central opening) | 800 mm | |
| Knee clearance height at lowest setting | 690 mm | |
| Cable grommet inner diameter | 80 mm | |
| Modesty panel thickness | 25 mm | |
| Support leg base trim height | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 180 kg | |
|---|---|---|
| Static load capacity of work surface | 120 kg | |
| Drawer slide durability cycles | 50000 | |
| Hinge durability cycles for cabinet doors | 80000 | |
| Recommended maximum user weight for seated/standing use | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | E0 grade particle board with light oak melamine finish | |
|---|---|---|
| Cabinet and modesty panels | E0 grade MDF with matte warm off-white paint finish | |
| Lift mechanism internal structure | 1.5mm thick cold-rolled steel frame with powder coating | |
| Edge banding | 2mm thick impact-resistant PVC edging matching panel finish | |
| Support leg plinth trim | Solid wood veneer oak trim matching worktop finish | |
| Pedestal lock hardware | Zinc alloy keyed cam lock with chrome finish | |
| Drawer slides | Full-extension cold-rolled steel ball-bearing slides | |
| Cable grommet | ABS plastic flush-mount grommet with brush seal | |
| Base leveling feet | Nylon adjustable glides with 10mm adjustment range | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment operation | Electric motor lift with 4 programmable height preset buttons | |
|---|---|---|
| Locking storage pedestal | Keyed lock securing 1 file drawer and 2 utility drawers | |
| Integrated power access | Embedded grommet with 2 AC outlets and 2 USB charging ports | |
| Under-desk cable management | Removable metal cable tray routed under main work surface | |
| Modesty panel coverage | Telescoping full-front modesty panel covering knee opening at all heights | |
| Storage return configuration | Left-side return combines open storage shelf and closed lockable cabinet | |
| Anti-collision protection | Motorized lift stops automatically when encountering obstacles | |
| Leveling adjustment | Base glides adjust to correct uneven floor surfaces up to 10mm | |
| Locking storage pedestal height | 730 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for director or manager offices, providing dual sit-stand workspace and lockable storage | |
|---|---|---|
| Home office premium workspace | Fits residential professional offices with modern two-tone aesthetic and cable management | |
| Single user dedicated workstation | Optimized for one professional user with ample work surface and file storage | |
| Standing meeting auxiliary use | Raised height supports short standing discussions or document review with visitors | |
| Open plan manager pod | Compatible with open office layouts when paired with low divider screens for privacy | |
| Executive office suite configuration | Pairs with matching visitor chairs and bookcases for a cohesive office furniture set | |
| Cable-heavy tech workstation | Integrated power ports and cable management suit multi-monitor computer setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office work table safety, strength and stability requirements | |
|---|---|---|
| EN 527-2:2016 | Applies to dimensional, adjustment and durability requirements for height-adjustable office desks | |
| EN 13722:2004 | Applies to test methods for strength and durability of office storage pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products structural performance, safety and durability test requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applies to storage units strength, durability and stability test requirements | |
| ANSI/BIFMA G1-2013 | Applies to ergonomic dimensional guidelines for seated and standing office work surfaces |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to desk dimensional, strength and durability testing requirements for office furniture | |
|---|---|---|
| GB/T 3324-2017 | Applies to general technical requirements for wooden office furniture panels and finishes | |
| GB 18580-2017 | Applies to formaldehyde emission limits for engineered wood panels used in furniture | |
| GB/T 4897.3-2003 | Applies to particle board physical and mechanical performance requirements for furniture use |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to desk dimensional, strength and durability testing requirements for office furniture; 2. GB/T 3324-2017: Applies to general technical requirements for wooden office furniture panels and finishes; 3. GB 18580-2017: Applies to formaldehyde emission limits for engineered wood panels used in furniture; 4. GB/T 4897.3-2003: Applies to particle board physical and mechanical performance requirements for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
