Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main top + left return) | 2400 x 2000 x 750 mm | |
|---|---|---|
| Main desktop thickness | 25 mm | |
| Structural side/modesty panel thickness | 16 mm | |
| Desktop edge corner radius | 30 mm | |
| PVC edge banding thickness | 2 mm | |
| Under-desk knee clearance height | 650 mm | |
| Under-desk knee clearance width (central opening) | 1600 mm | |
| Main desktop usable depth | 900 mm | |
| Left return credenza work depth | 600 mm | |
| Recessed plinth base height above floor | 50 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Fluted front panel slat width | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide rated load per drawer | 35 kg | |
| Drawer slide durability cycle count | 50000 cycles | |
| Soft-close hinge durability cycle count | 80000 cycles | |
| Integrated power outlet rated current | 10 A | |
| Recommended maximum user weight for seated use | 150 kg | |
| Surface finish abrasion resistance (Taber test) | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main desktop core | E0-grade low-emission particleboard | |
|---|---|---|
| Desktop surface finish | Walnut-toned natural wood veneer with matte clear lacquer | |
| Base and return cabinet panels | Champagne-beige matte lacquered MDF | |
| Front modesty panel | Fluted MDF with matte champagne lacquer | |
| Edge trim | 2mm thick high-temperature resistant PVC edge banding | |
| Recessed base plinth | Powder-coated steel frame with lacquered toe kick | |
| Hardware components | Zinc-alloy soft-close hinges, three-section ball-bearing drawer slides, keyed storage locks | |
| Ambient lighting | Low-voltage 3000K warm white LED strip with diffuser cover | |
| Integrated power unit | Dual AC power outlets with dual USB charging ports | |
| Cable management components | ABS cable grommet lid, under-desk steel cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Left fixed return credenza with 2 lockable file drawers and 1 open storage compartment | |
|---|---|---|
| Cable management system | Desktop grommet feeds cables to under-desk tray, conceals wiring from work surface | |
| Integrated power access | Side-panel power/USB unit allows convenient device charging without desktop clutter | |
| Ambient lighting function | Dimmable warm white LED strip behind fluted panel provides indirect under-desk illumination | |
| Drawer operation | Full-extension soft-close drawers with keyed locks for secure document storage | |
| Assembly structure | Knock-down flat-pack construction with cam-lock connectors for on-site assembly | |
| Surface protection | Stain-resistant matte lacquer finish resists daily coffee, ink and paper wear | |
| Weight distribution design | Full perimeter plinth base distributes weight evenly, no sharp floor contact points | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for CEO, director or senior manager private workspaces with premium aesthetic requirements | |
|---|---|---|
| Corporate headquarters office suites | Coordinates with matching illuminated open-shelf bookcase for cohesive executive suite layout | |
| High-end government/enterprise leadership offices | Provides formal, professional appearance and functional storage for daily executive work | |
| Recommended paired furniture | Matches with high-back leather executive chair, visitor seating and matching lateral file cabinet | |
| Space size requirement | Recommended for rooms with minimum 3.6m x 3.0m clear floor area to fit return and seating | |
| Primary use case | Supports daily computer work, document review, small in-office meetings and device charging |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural load and stability verification | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units performance requirements, applicable for return cabinet durability verification | |
| EN 717-1:2004 | Wood-based panels formaldehyde emission determination, applicable for low-emission board acceptance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for load, durability and stability acceptance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for return cabinet and drawer cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability and finish quality acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for core panel mechanical property verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability and finish quality acceptance; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for core panel mechanical property verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
