Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (HDA02-2810) | 2800 x 1000 x 750 mm | |
|---|---|---|
| Desk top thickness | 40 mm | |
| Edge band (brushed metal trim) thickness | 2 mm | |
| Seated knee clearance height | 650 mm | |
| Seated knee clearance width (chair side) | 1200 mm | |
| Integrated writing pad dimensions | 1200 x 600 mm | |
| Cable grommet diameter | 80 mm | |
| Base wall thickness (metallic panel) | 25 mm | |
| Top corner radius | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desk top static load capacity | 120 kg | |
|---|---|---|
| Net product weight | 130 kg | |
| Recommended user count | 1 | |
| Surface abrasion resistance | 2000 cycles | |
| Standard product warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desk top substrate | E1 grade high-density MDF board | |
|---|---|---|
| Desk top surface finish | High-gloss scratch-resistant matte lacquer | |
| Integrated writing pad | PU leather writing surface with non-slip backing | |
| Support base | Brushed metallic finish MDF core with stainless steel cladding | |
| Desktop perimeter trim | Brushed champagne gold stainless steel edge band | |
| Cable grommet | Zinc alloy brushed metal cable port | |
| Base footing pads | Non-marking rubber floor protection pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Embedded cable grommet routes monitor/device cords under desk | |
|---|---|---|
| Work surface layout | Dedicated front writing zone and rear equipment zone defined by integrated pad | |
| Height configuration | Fixed 750 mm ergonomic work height for seated office use | |
| Stability design | Curved wide-spread sculpted base eliminates wobble under normal office loads | |
| Floor protection | Full perimeter rubber footing prevents scuffing on hard floors and rugs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Private executive CEO/Director office, paired with matching leather executive chair | |
|---|---|---|
| Recommended flooring | Suitable for area rugs, polished wood, tile and stone office flooring | |
| Supporting furniture match | Pairs with matching low office storage credenzas and bookcases | |
| User profile | Designed for senior management requiring large, formal work surface for documents and devices | |
| Work type suitability | Supports desktop computer, document review, video conferencing and executive meetings at desk |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for contract procurement | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables mechanical safety test methods for structural validation | |
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion for desk top finishes |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance in office use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desk structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for E1 grade board acceptance | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to desk core substrates |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desk structural performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for E1 grade board acceptance; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to desk core substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
