Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1000 × 760 mm | |
|---|---|---|
| Overall dimensions | 2400 x 1000 x 760 mm | |
| Left pedestal dimensions | 900 x 700 x 650 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 135 kg | |
|---|---|---|
| Distributed desktop load | 80 kg | |
| Pedestal cabinet load | 30 kg per shelf or storage compartment | |
| Drawer slide load | 25 kg per drawer if fitted | |
| Recommended user capacity | 1 person | |
| Floor contact points | 4 adjustable glides, 2 per pedestal | |
| Suggested seating seat-height range | 500 mm | |
| Surface impact use | Normal office writing and computer use | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | 18 mm moisture-resistant wood-based panel with dark wood-veneer or melamine face | |
|---|---|---|
| Edge construction | Rounded dark laminated edge with 50 mm visible built-up profile | |
| Pedestal panels | 18 mm light beige painted or melamine-faced wood-based panels | |
| Interior structure | Panel-board carcass with vertical divider and horizontal storage partition | |
| Door and drawer fronts | Flush light panel fronts bordered by 30 mm dark accent rails | |
| Hardware | 70 mm dark circular metal-style pulls with recessed center detail |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Two enclosed pedestal cabinets, each with a 2-door face and horizontal front partition providing 4 visible front sections | |
|---|---|---|
| Seated work position | Centered 750 mm knee bay between the left and right storage cabinets | |
| Cable management | Supplier should provide at least one 60 mm desktop grommet or rear cable channel; the visible top has no clearly readable outlet | |
| Door operation | Hinged or sliding panel fronts with paired circular pulls; actual hinge type and drawer count must be confirmed by factory drawing |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Suitable for a manager or director office requiring writing, computer work and two-side enclosed storage | |
|---|---|---|
| Meeting-adjacent workspace | Can serve in a high-end reception office or consultation room where documents and display objects remain accessible |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
