Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1050 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Net product weight | 180 kg | |
| Recommended user count | 1 | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Drawer slide cycle rating | 50000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop core | 25mm E1 grade MDF with wood veneer surface | |
|---|---|---|
| Desktop edge | Solid walnut wood edge banding with radius 30mm rounded profile | |
| Cabinet front panel | 18mm MDF with high-gloss gray lacquer finish | |
| Decorative accent strip | Solid walnut wood inlay with chamfered end | |
| Edge trim | Brushed 304 stainless steel trim | |
| Base plinth | 15mm MDF with matching wood veneer | |
| Storage drawer boxes | 15mm plywood dovetail construction | |
| Modesty panel backer | 12mm MDF matching gray lacquer finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Left pedestal storage | 2 soft-closing drawers + 1 lockable file drawer for A4/legal documents | |
|---|---|---|
| Cable management | 2 desk grommets on desktop rear edge with under-desk cable tray | |
| Fixed work surface | Height-fixed desktop positioned at 750mm standard office working height | |
| Drawer operation | Soft-close full-extension ball-bearing slides with 450mm travel | |
| Central lock system | One key locks all storage drawers for document security | |
| Levelling feet | Adjustable nylon levelling feet with 15mm adjustment range at base corners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Suitable for senior management standalone offices, supports desktop monitor, laptop and document processing | |
|---|---|---|
| Corporate boardroom side desk | Usable as a presentation or host desk in high-end meeting rooms | |
| High-end home office | Ideal for large home study spaces requiring professional storage and executive styling | |
| Reception manager workspace | Appropriate for upscale hotel or corporate reception manager stations | |
| Recommended matching chair | Pair with high-back upholstered leather executive chairs with 500 mm seat height | |
| Clear floor space requirement | Minimum 3400 x 2050 mm clear floor area for full access and chair movement |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables - Dimensional requirements | |
| EN 13722:2004 | Furniture - Strength and durability of storage units |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2003 | Particleboard for furniture use | |
| GB 28007-2011 | Safety requirements for children's furniture (non-applicable reference only) |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 18580-2017: Formaldehyde emission limits for wood-based panels; 3. GB/T 4897.3-2003: Particleboard for furniture use; 4. GB 28007-2011: Safety requirements for children's furniture (non-applicable reference only); Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
