| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk + return) | 2200 x 1750 x 750 mm | |
|---|---|---|
| Main work surface width | 1800 mm | |
| Main work surface depth | 800 mm | |
| Seated knee clearance width | 1400 mm | |
| Seated knee clearance height | 650 mm | |
| Return cabinet width | 1200 mm | |
| Return cabinet depth | 600 mm | |
| Open shelf internal height per tier | 300 mm | |
| Worktop panel thickness | 25 mm | |
| Modesty panel thickness | 18 mm | |
| Edge banding thickness | 2 mm | |
| Cable management port diameter | 80 mm | |
| Angled cantilever leg wall thickness | 1.2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Product net weight | 90 kg | |
|---|---|---|
| Main worktop static load capacity | 150 kg | |
| Recommended maximum user count | 1 person | |
| Surface abrasion resistance rating | 2000 cycles | |
| Adjustable foot vertical adjustment range | 15 mm | |
| Product warranty | 5 years | |
| Available finish options | 3 options | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop surface | Light grey stone-effect high-pressure laminate over E0-grade particle board | |
|---|---|---|
| Cabinet and modesty panels | Dark grey matte melamine-faced engineered wood | |
| Support frame and cantilever leg | Powder-coated cold-rolled steel tubing | |
| Edge banding | 2mm thick impact-resistant PVC edging | |
| Open shelf dividers | 18mm thick melamine-faced engineered wood | |
| Cable port cover | Ventilated ABS plastic with brush seal | |
| Adjustable feet | Reinforced nylon with threaded steel insert | |
| Integrated desk management tray | Matte black ABS plastic integrated into central work surface | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Side ventilation cable port routes power/data cables from work surface to under-desk area | |
|---|---|---|
| Return storage configuration | Two open fixed shelves provide accessible storage for books, decor and office supplies | |
| Leg leveling mechanism | Threaded adjustable feet compensate for uneven floor surfaces up to 15mm vertical travel | |
| Modesty panel function | Full-width front modesty panel conceals under-desk wiring and user leg area for privacy | |
| Cantilever leg support | Angled left steel leg provides unobstructed leg room without intermediate support posts | |
| Integrated desk tray | Central raised mat/tray organizes keyboard, mouse and writing accessories for defined work zones | |
| Under-desk clearance | 650mm knee height accommodates standard ergonomic office chairs with lumbar support | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Sized for CEO, director or senior manager workspaces with professional modern aesthetic | |
|---|---|---|
| Open-plan management workstation | Provides dedicated work zone with integrated storage for team lead work areas | |
| High-end home office | Contemporary minimalist design suits dedicated residential office spaces for remote executives | |
| Meeting room leader station | Functions as a presentation work surface for small in-room meeting discussions | |
| Recommended chair pairing | High-back ergonomic executive office chair with gas lift adjustment for 520 mm seat height | |
| Recommended accessory pairing | Under-desk cable tray, monitor arm and lockable drawer insert for enhanced functionality |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables dimensional and safety requirements, applicable to ergonomic work height and clearance | |
|---|---|---|
| EN 527-2:2016 | Office worktables mechanical safety and stability requirements, applicable to load rating verification | |
| EN 13722:2004 | Furniture strength and durability for storage units, applicable to open shelf load performance | |
| EN 71-3:2019 | Migration of certain elements for surface finishes, applicable to non-toxic coating requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for static, dynamic and cycle load testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for shelf and cabinet structural durability | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and recyclability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and cabinet panel construction | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks, applicable to dimensional and stability performance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0-grade panel material selection | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to worktop laminate durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and cabinet panel construction; 2. GB/T 3327-2016: Technical requirements for office desks, applicable to dimensional and stability performance; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0-grade panel material selection; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to worktop laminate durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
