| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall L-shape footprint | 2800 x 2200 x 760 mm | |
|---|---|---|
| Main desktop thickness | 50 mm | |
| Raised carved edge trim thickness | 20 mm | |
| Main work surface depth | 1150 mm | |
| Seated knee clearance height | 600 mm | |
| Seated knee clearance width | 1600 mm | |
| Mobile return cabinet dimensions | 1200 x 600 x 650 mm | |
| Cable grommet diameter | 60 mm | |
| Modesty panel height | 600 mm | |
| Caster wheel diameter | 50 mm | |
| Integrated desk pad dimensions | 1200 x 500 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide dynamic load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge open/close cycle rating | 80000 cycles | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Total set net weight | 160 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 18mm high-density fiberboard | |
|---|---|---|
| Desktop surface veneer | 0.6mm mahogany-toned natural wood veneer | |
| Desktop finish | High-gloss UV-cured lacquer | |
| Decorative trim and edges | Solid hardwood carved molding | |
| Front modesty panel | 15mm HDF with wood veneer and framed carving | |
| Integrated desk pad | 2mm black polyurethane surface over 5mm foam backing | |
| Cable grommets | Brushed ABS plastic with removable cover | |
| Mobile return casters | 360-degree swivel nylon casters with brake | |
| Drawer hardware | Cold-rolled steel ball-bearing slides with central lock | |
| Support panel core | 25mm particleboard with matching veneer finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Two 60mm desktop grommets route power/data cables to under-desk space | |
|---|---|---|
| Mobile return storage | Caster-mounted side return with 3 lockable drawers slides for flexible positioning | |
| Central drawer locking | Single key lock secures all return cabinet drawers simultaneously | |
| Writing surface integration | Fixed black PU desk pad provides smooth, non-slip writing zone | |
| Front modesty privacy | Full-height front panel blocks leg visibility from office entry | |
| Floor protection | Swivel casters on return prevent floor scuffing during repositioning | |
| Edge safety | Rounded carved top edges eliminate sharp contact points at work surface | |
| Storage configuration | Closed cabinet storage in main desk supports and mobile return conceals office supplies | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits 25sqm senior management offices for formal corporate settings | |
|---|---|---|
| Boardroom auxiliary workspace | Serves as dedicated presenter or chairman work surface in large meeting rooms | |
| Government/official office | Appropriate for institutional offices requiring traditional, authoritative furniture styling | |
| Private study/home office | Works in high-end residential studies for executive remote work use | |
| Reception manager workspace | Serves as behind-reception work area for senior reception or administrative staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural performance verification | |
|---|---|---|
| EN 15372:2016 | Office furniture storage units strength and durability requirements, applicable for cabinet sections |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for mobile return cabinet verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural quality verification | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for substrate performance verification | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for emission checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural quality verification; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for substrate performance verification; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for emission checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
