| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1850 x 750 mm | |
|---|---|---|
| Main worktop size | 2200 x 1000 x 50 mm | |
| Left return cabinet size | 1800 x 600 x 630 mm | |
| Seated knee clearance height | 615 mm | |
| Worktop edge thickness | 50 mm | |
| Fluted modesty panel height | 600 mm | |
| Cable grommet diameter | 80 mm | |
| Return cabinet drawer internal height | 150 mm | |
| Base support wall thickness | 18 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide dynamic load rating | 25 kg | |
| Drawer slide cycle life | 50000 cycles | |
| Integrated LED strip power | 12 W | |
| Recommended user weight capacity | 150 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E1-grade engineered wood | |
|---|---|---|
| Worktop finish | Light oak matte melamine veneer | |
| Base support panels | Taupe matte MDF | |
| Front modesty panel | Fluted/ribbed taupe MDF | |
| Edge banding | 2 mm PVC matching edge trim | |
| Drawer hardware | Soft-close full-extension steel slides | |
| Lock mechanism | Keyed central drawer lock | |
| Lighting component | 3000K warm white LED strip | |
| Leveling components | Nylon adjustable leveling glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Left-side return cabinet with 3 lockable drawers | |
|---|---|---|
| Cable management | Dual 80mm desk grommets with under-desk cable tray | |
| Ambient lighting | Integrated dimmable under-desk LED strip | |
| Drawer operation | Soft-close self-latching drawer slides | |
| Return orientation | Fixed left-side return configuration | |
| Floor leveling | Adjustable 15mm travel leveling glides | |
| Surface protection | Scratch, stain, and water-resistant melamine finish | |
| Knee well access | Central open knee bay for ergonomic seated work | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total packaged gross weight | 185 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suits CEO/manager private offices, provides professional workspace and storage | |
|---|---|---|
| Home executive office | Fits upscale home offices with matching storage and modern aesthetic | |
| Corporate boardroom annex | Works as dedicated workspace adjacent to formal meeting spaces | |
| Single user daily work | Supports 8+ hours daily seated computer and document work | |
| Matching storage suite | Pairs with matching back wall open/closed storage bookcases visible in scene | |
| Carpeted office environments | Leveling glides adjust correctly for commercial loop or pile carpet |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for structural performance | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and ergonomic requirements | |
| EN 13722:2004 | Furniture strength and durability for storage units integrated into desks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard applicable for integrated return cabinet performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desk structural integrity | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood substrate compliance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for indoor air quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desk structural integrity; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood substrate compliance; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for indoor air quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
