Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 1800 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Main desktop surface dimensions | 1800 x 900 mm | |
| Left return storage top dimensions | 900 x 600 mm | |
| Seated knee clearance width | 1200 mm | |
| Seated knee clearance height | 620 mm | |
| Seated knee clearance depth | 500 mm | |
| Side CPU cabinet dimensions | 600 x 600 x 650 mm | |
| Gold edge trim thickness | 2 mm | |
| Plinth base foot height | 40 mm | |
| Cable grommet diameter | 80 mm | |
| Vent slot dimensions | 80 x 10 mm | |
| Under-desk LED strip length | 1000 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop distributed static load capacity | 227 kg | |
|---|---|---|
| Net product weight | 182 kg | |
| Drawer slide static load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet door hinge cycle rating | 100000 cycles | |
| Recommended user weight capacity | 159 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop core | 18mm thick MDF substrate with high-density fiberboard reinforcement | |
|---|---|---|
| Desktop finish | Scratch-resistant matte dark gray melamine laminate | |
| Edge trim | Gold-plated 304 stainless steel trim with polished finish | |
| Cabinet body | 15mm thick particleboard core with matching matte dark laminate | |
| Accent grille | Perforated gold-painted steel panel covering integrated LED light strip | |
| Base feet | Reinforced ABS plastic foot pads with scratch-resistant felt bottom |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Left vented CPU cabinet, central file drawer, right side support cabinet | |
|---|---|---|
| Cable management | Recessed desktop cable grommet routed to internal under-desk cable channel | |
| Ambient lighting | Integrated warm-white LED strip behind perforated gold grille at knee opening | |
| Equipment ventilation | Three horizontal vent slots on left cabinet side for CPU tower airflow |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Formal luxury design suitable for director and C-suite workspaces | |
|---|---|---|
| Managerial work area | Large work surface and integrated storage for daily administrative tasks |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office work tables safety and strength requirements for commercial office use | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for non-domestic seating and tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural performance and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural integrity | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to cabinet core panel grade | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural integrity; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to cabinet core panel grade; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
