Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1000 x 760 mm | |
|---|---|---|
| Right storage return dimensions | 1200 x 650 x 660 mm | |
| Central knee clearance width | 1200 mm | |
| Knee clearance height under desktop | 660 mm | |
| Desktop total thickness | 40 mm | |
| Chrome star support leg diameter | 80 mm | |
| Storage cabinet panel thickness | 60 mm | |
| Edge banding thickness | 8 mm | |
| Metallic top edge trim width | 5 mm | |
| Cable grommet inner diameter | 80 mm | |
| Adjustable foot height adjustment | 15 mm | |
| Modesty panel thickness | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle life | 50000 cycles | |
| Door hinge cycle life | 80000 cycles | |
| Finish hardness rating | 2H | |
| Desk net weight | 185 kg | |
| Recommended user weight capacity | 150 kg | |
| Wood panel moisture content | 12% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | High-density fiberboard core | |
|---|---|---|
| Desktop surface | 0.6 mm thick polished natural wood veneer | |
| Desktop edge | Solid wood edge band with polished chrome metallic trim | |
| Left support leg | Polished chrome plated steel star frame, 1.5 mm wall thickness | |
| Right storage return cabinet | Lacquered MDF with rounded edge profile, matte two-tone finish | |
| Storage hardware | Soft-close hydraulic hinges and three-section silent ball-bearing slides | |
| Modesty panel | 15 mm thick lacquered MDF, matching cabinet finish | |
| Leveling feet | Nylon base adjustable feet with chrome plated stem | |
| Cable management components | ABS plastic cable grommets with brushed metal cover, steel under-desk cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Two soft-close drawers and one enclosed cabinet compartment in right return | |
|---|---|---|
| Cable management | Two desk-top cable grommets connected to under-desk cable tray for wire routing | |
| Leveling adjustment | Adjustable nylon feet on all base contact points to correct uneven floors | |
| Hardware operation | Soft-close hinges and slides eliminate slamming, with 80 mm drawer extension travel | |
| Surface resistance | Lacquer finish resists scratches, 120°C short-term heat, and common household stains | |
| Assembly structure | Knock-down construction with steel cam-lock connectors for on-site assembly | |
| Knee access | Open central knee recess provides unobstructed legroom for seated executive users | |
| Edge protection | Rounded profile edges on all cabinet and desk corners reduce impact injury risk | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Private executive offices and CEO suites | |
|---|---|---|
| Target user group | C-suite executives, senior managers, and private office users | |
| Matching furniture set | Pairs with high-back leather executive chair and matching illuminated display cabinet | |
| Suitable commercial grade | Class A commercial office buildings and high-end corporate headquarters | |
| Recommended layout | Positioned 1500 mm from rear wall for chair clearance and cabinet access | |
| Recommended surface use | Supports laptop, desktop monitor, desk lamp and standard office work materials |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial office use | |
|---|---|---|
| EN 13722:2004 | Furniture strength, durability and stability requirements for storage components | |
| EN 12521:2015 | Furniture mechanical safety requirements for contract office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for strength, durability and structural stability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for office furniture performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to this wood veneer desk | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture, E1 grade required | |
| GB/T 4897.3-2003 | Particleboard/fiberboard specification for furniture structural use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to this wood veneer desk; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture, E1 grade required; 3. GB/T 4897.3-2003: Particleboard/fiberboard specification for furniture structural use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
