Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1000 x 750 mm | |
|---|---|---|
| Worktop thickness | 50 mm | |
| Drawer panel thickness | 18 mm | |
| Edge banding thickness | 2.0 mm | |
| Central knee clearance width | 1200 mm | |
| Central knee clearance height | 650 mm | |
| Shallow utility drawer internal dimensions | 450 x 400 x 120 mm | |
| Deep file drawer internal dimensions | 450 x 400 x 280 mm | |
| Recessed work zone dimensions | 1600 x 600 mm | |
| Cable management slot length | 800 mm | |
| Pedestal base radius | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 210 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Leveler adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core | E0 grade engineered wood board | |
|---|---|---|
| Worktop surface finish | Matte two-tone polyurethane lacquer | |
| Drawer front panels | Brown wood-grain veneer over engineered wood | |
| Pedestal base enclosure | Matte light off-white engineered wood with soft rounded edges | |
| Drawer slides | Full-extension steel ball-bearing soft-close slides | |
| Drawer locks | Brushed metal cam locks with key operation | |
| Edge treatment | 2mm PVC edge banding with chamfered bevel profile | |
| Base leveling feet | Nylon-padded adjustable steel feet | |
| Cable management channel | Recessed steel wire raceway with brushed metal cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Drawer storage configuration | Two stacked drawers per pedestal: one shallow utility drawer, one deep locking file drawer | |
|---|---|---|
| Drawer operation | Soft-close full-extension slides with 100% drawer access and automatic soft-close in final 50mm of travel | |
| Drawer locking | Keyed cam lock per upper drawer to secure both drawers in each pedestal | |
| Cable management | Recessed linear desktop slot feeding to under-desk cable tray for wire routing to floor outlets | |
| Floor leveling | Adjustable feet at each pedestal corner to correct uneven floor surfaces up to 15mm height difference | |
| Work surface design | Recessed textured work zone to define primary keyboard/monitor area and contain desk accessories | |
| Edge protection | Chamfered beveled edges eliminate sharp corners and reduce impact damage during use | |
| Storage security | Lockable drawers secure confidential documents and office valuables when not in use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suited for CEO and senior manager offices as primary work surface, dual pedestals provide storage privacy | |
|---|---|---|
| High-end home office | Premium two-tone finish fits luxury residential office spaces for executive remote work | |
| Boardroom auxiliary workspace | Can be used as meeting room side work surface for document prep and meeting material storage | |
| Commercial corporate interiors | Pairs with matching wall storage casegoods visible in background for cohesive office design schemes | |
| Seated workstation use | Fixed 750mm height aligns with standard ergonomic office chairs for all-day seated work | |
| Private client meeting use | Wide worktop supports in-desk meetings across the surface with visitors seated opposite |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to commercial office desk performance | |
|---|---|---|
| EN 527-2:2002 | Office work tables mechanical safety test methods for structural durability verification | |
| EN 12520:2015 | Furniture strength, durability and safety requirements for seating-adjacent office tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance for commercial office use | |
|---|---|---|
| ANSI/BIFMA M7.1-2020 | Standard test method for emissions from office furniture systems for indoor air quality |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish performance | |
|---|---|---|
| GB/T 3327-2017 | Performance test methods for desks and tables, applicable to load and stability verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish performance; 2. GB/T 3327-2017: Performance test methods for desks and tables, applicable to load and stability verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
