Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2800 x 2200 x 750 mm | |
|---|---|---|
| Main work surface width | 2200 mm | |
| Main work surface depth | 1000 mm | |
| Side return width | 2000 mm | |
| Side return depth | 600 mm | |
| Side return surface height | 600 mm | |
| Desktop thickness | 40 mm | |
| Seated knee clearance height | 650 mm | |
| Cable grommet diameter | 80 mm | |
| Cabinet base plinth height | 50 mm | |
| Brass accent trim thickness | 2 mm | |
| PVC edge band thickness | 2 mm | |
| Internal drawer width | 500 mm | |
| Internal drawer depth | 470 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Main desktop static load capacity | 136 kg | |
|---|---|---|
| Drawer slide static load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 100000 cycles | |
| Surface scratch resistance | Class 2 | |
| Surface heat resistance | 80 °C | |
| Net product weight | 200 kg | |
| Recommended maximum user weight for work surface use | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main desktop and return surface | E1 grade MDF core with scratch-resistant light walnut melamine laminate | |
|---|---|---|
| Cabinet body panels | E1 grade particleboard core with charcoal matte melamine finish | |
| Decorative trim | Brass-toned brushed stainless steel accent strip | |
| Edge banding | 2mm thick PVC edge matching top and panel finishes | |
| Support feet | High-strength engineered wood block feet with matching finish | |
| Storage hardware | Steel soft-close ball-bearing drawer slides, concealed cabinet hinges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Two recessed desktop cable ports with under-desk routing tray | |
|---|---|---|
| Side return storage | Enclosed cabinet compartments with 4 soft-close storage drawers | |
| Stepped work surface design | Elevated main worktop 150mm above lower return surface | |
| Stable fixed panel base | Enclosed box-style base with no protruding legs for unobstructed knee space |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Suits manager/director offices with 15sqm dedicated workspace | |
|---|---|---|
| Home office luxury setup | Fits upscale home offices requiring dedicated work and document storage |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables - Safety and strength requirements for executive work surfaces | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety for office storage units | |
| EN 14322:2017 | Melamine faced panels for furniture, surface performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products - Performance and safety standard for office work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units - Performance and safety standard for integrated cabinetry |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and structural performance | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to cabinet body structural panels | |
| GB/T 11718-2009 | Medium density fiberboard (MDF) for furniture, applicable to desktop core material | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade requirement for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and structural performance; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to cabinet body structural panels; 3. GB/T 11718-2009: Medium density fiberboard (MDF) for furniture, applicable to desktop core material; 4. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade requirement for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
