| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W x D x H) | 2400 x 1800 x 765 mm | |
|---|---|---|
| Main work surface height | 765 mm | |
| Main raised desktop panel thickness | 50 mm | |
| Side return work surface depth | 600 mm | |
| Side return work surface height | 720 mm | |
| Plinth base height | 690 mm | |
| Knee clearance height | 680 mm | |
| Knee clearance width | 800 mm | |
| Desktop edge band thickness | 2 mm | |
| Pop-up connectivity hub cutout diameter | 80 mm | |
| Drawer front height | 300 mm | |
| Gold decorative trim width | 12 mm | |
| Curved cabinet end radius | 120 mm | |
| Cable management channel width | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 127 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 100000 cycles | |
| Surface wear resistance | 2000 revolutions | |
| Product net weight | 159 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop core substrate | 18mm thick CARB P2 grade MDF with steel internal reinforcement | |
|---|---|---|
| Desktop surface finish | Matte taupe faux leather-textured laminate with scratch and stain resistance | |
| Base cabinet panels | 18mm thick dark charcoal matte laminate MDF with rounded edge profile | |
| Decorative accents | 0.8mm thick brushed gold-tone aluminum trim recessed into drawer fronts | |
| Edge banding | 2mm thick matching PVC edge banding heat-fused to all panel edges | |
| Drawer hardware | Zinc alloy soft-close drawer slides with optional mechanical drawer lock |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated pop-up hub | Flip-up unit with AC power, USB-A/USB-C charging and network port, recessed flush when closed | |
|---|---|---|
| Under-desk cable management | Concealed rear routing channel with access cutouts to route cables to wall outlets | |
| Enclosed storage | Full-width soft-close drawers along plinth base for office supplies and hanging file storage | |
| Stepped work surface | Elevated main work surface and lower side return for document placement or secondary devices |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Suits CEO and senior manager offices, providing large work surface and confidential storage | |
|---|---|---|
| High-end corporate workspace | Matches luxury modern office interiors with gold accent trim and two-tone finish |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance verification | |
|---|---|---|
| EN 13722:2004 | Furniture test for storage unit strength and durability, applicable to drawer performance verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office products desk products standard, applicable to load, stability and cycle testing for commercial use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel strength and finish durability | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture, applicable to composite wood substrate emissions | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to desktop static load and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel strength and finish durability; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture, applicable to composite wood substrate emissions; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to desktop static load and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
