Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 1800 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide operational cycle life | 50000 cycles | |
| Door hinge operational cycle life | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Overall product structural service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 25 mm E1-grade MDF core with 0.6 mm dark walnut wood grain melamine laminate | |
|---|---|---|
| Desktop edging | 2 mm matte black PVC edge banding, hot-melt glued for impact resistance | |
| Pedestal and modesty panels | 18 mm E1-grade particleboard substrate with warm taupe matte powder-coat effect finish | |
| Accent trim | 15 mm wide brushed 304 stainless steel horizontal strips, recessed into front modesty panel | |
| Pedestal drawer slides | Cold-rolled steel full-extension ball-bearing slides, zinc-plated for corrosion resistance | |
| Storage door hinges | Cold-rolled steel soft-close concealed hinges, nickel-plated finish | |
| Base leveling glides | 10 mm diameter nylon adjustable glides with threaded steel inserts | |
| Cable grommets | ABS plastic brushed silver finish desk grommets with removable brush seal | |
| Under-desk cable tray | 1 mm thick cold-rolled steel powder-coated black tray, mounted under desktop | |
| Pedestal lock core | Zinc alloy keyed cam lock with two matching keys, keyed-alike option available | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Fixed height work surface | Rigid welded box frame supports work surface at 760 mm working height, no height adjustment mechanism | |
|---|---|---|
| Cable management system | Dual brush-seal grommets route power/data cables to under-desk steel tray, eliminating desktop clutter | |
| CPU compartment ventilation | Vertical slotted vents on left pedestal side panel provide passive airflow for tower PC stored inside pedestal | |
| Lockable pedestal storage | Keyed cam lock secures 2 utility drawers and 1 hanging file drawer in left pedestal for confidential document storage | |
| Soft-close storage hardware | Drawer slides and door hinges include dampers to close silently without slamming during daily use | |
| Leveling adjustment | Threaded nylon glides at each base corner adjust up to 10 mm to compensate for uneven floor surfaces | |
| Modesty panel privacy | Full-width front modesty panel blocks view of under-desk leg area from front visitor seating positions | |
| Return work surface support | Left side return provides 600 mm deep auxiliary space for printer, documents or secondary monitor placement | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 4897.3-2003 Particleboard - Part 3 | Requirements for furniture-grade boards, applies to panel substrate quality |
|---|
This product must meet the following technical requirements: 1. GB/T 4897.3-2003 Particleboard - Part 3: Requirements for furniture-grade boards, applies to panel substrate quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
