Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1000 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Silver edge trim thickness | 2 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1200 mm | |
| Pedestal height | 600 mm | |
| Pedestal depth | 700 mm | |
| Cable grommet diameter | 80 mm | |
| Edge banding radius | 30 mm | |
| Plinth base height | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Net product weight | 105 kg | |
| Recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop surface | Low-pressure laminate over high-density fiberboard core | |
|---|---|---|
| Perimeter edge trim | Brushed silver aluminum alloy | |
| Storage pedestal cabinets | Medium-density fiberboard with light oak wood veneer | |
| Modesty panel | Matte off-white lacquered fiberboard | |
| Plinth base trim | Powder-coated silver steel | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing hardware | |
| Drawer panel substrate | 18 mm thick particleboard with matching wood veneer | |
| Core structural frame | 25 mm thick engineered wood support rails | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Rear recessed grommet routes power/data cables from desktop to under-desk space | |
|---|---|---|
| Left pedestal storage | Two equal-width cabinet doors enclosing adjustable shelves for office supplies | |
| Right pedestal storage | Two side-by-side file drawers compatible with letter/legal hanging folders | |
| Pedestal support | Dual plinth-base cabinets elevate desktop, eliminating need for separate legs | |
| Floating desktop effect | Desktop sits on raised central support between pedestals for modern aesthetic | |
| Leveling adjustment | Integrated adjustable glides under plinth bases compensate for uneven floors | |
| Drawer operation | Full-extension slides allow full access to drawer contents without tipping | |
| Surface protection | Scratch and stain resistant laminate finish resists daily office wear | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Designed for senior management workspaces with dual-side storage for files and supplies | |
|---|---|---|
| Corporate management suite | Professional two-tone finish matches high-end commercial office interior design schemes | |
| Dual-monitor workstation | 1000 mm depth accommodates multiple monitors, peripherals and work documents | |
| Small conference meeting use | Wide desktop supports small in-person document review meetings across the desk | |
| Hybrid home executive office | Polished design works for both professional video calls and residential home office settings |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety and stability test methods | |
| EN 13722:2004 | Furniture strength and durability requirements for storage units in office pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability, and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for pedestal drawer strength and cycle performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural stability | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for desks and tables, applicable to load and durability testing | |
| GB 18584-2001 | Formaldehyde emission limits for interior wooden furniture, applicable to panel material safety | |
| GB/T 4897-2015 | Particleboard specification, applicable to cabinet substrate material quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural stability; 2. GB/T 3327-2016: Performance test methods for desks and tables, applicable to load and durability testing; 3. GB 18584-2001: Formaldehyde emission limits for interior wooden furniture, applicable to panel material safety; 4. GB/T 4897-2015: Particleboard specification, applicable to cabinet substrate material quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
