Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 1800 x 760 mm | |
|---|---|---|
| Main desktop depth | 800 mm | |
| Left return worktop width | 800 mm | |
| Left return worktop depth | 500 mm | |
| Tabletop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance height under main desk | 650 mm | |
| Knee clearance width | 1200 mm | |
| Modesty panel height | 450 mm | |
| Cable grommet opening size | 80 mm | |
| Side support panel thickness | 36 mm | |
| Return cabinet ventilation slit length | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide rated load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Cabinet hinge cycle rating | 80000 open/close cycles | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Net weight (assembled) | 145 kg | |
| Recommended maximum user weight supported | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | E1-grade particleboard | |
|---|---|---|
| Tabletop finish | Dark walnut wood-grain thermoformed melamine | |
| Cabinet body and base | E1-grade MDF with warm taupe matte finish | |
| Front modesty panel | Horizontal ribbed engineered wood with taupe matte finish | |
| Storage door/drawer panels | Matching taupe engineered wood with integrated pull handles | |
| Hardware components | Zinc alloy lock cylinders, steel soft-close slides | |
| Cable grommet | ABS plastic with black brush insert | |
| Leveling glides | Nylon base with steel threaded stem | |
| Edge banding | 2mm thick PVC matching tabletop finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Recessed brush grommet routes cables from desktop to under-desk tray | |
|---|---|---|
| Left return storage | Ventilated enclosed cabinet sized for CPU tower and hanging files | |
| Drawer operation | Soft-close full-extension slides with keyed lock for secure document storage | |
| Privacy modesty panel | Full-width ribbed front panel blocks view of seated user's legs | |
| Edge protection | Rounded thermoformed edges on return corner reduce impact injury | |
| Leveling adjustment | Threaded nylon glides adjust 15mm to compensate for uneven office floors | |
| Storage access | Flush integrated handle design for cabinet doors and drawers for clean aesthetic | |
| Work surface zoning | Main 1200mm section for monitor/laptop, return section for peripheral devices | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Designed for manager or director level private office use | |
|---|---|---|
| Home office workspace | Suitable for high-end residential workspaces with professional aesthetic | |
| Corporate boardroom ancillary space | Usable as auxiliary work surface in executive meeting suites | |
| Single seated user configuration | Optimized for one primary user with centered seating position | |
| Pairing with high-back executive chairs | 650mm knee clearance accommodates standard high-back office chairs | |
| Project office furniture procurement | Suitable for bulk commercial office fit-out projects |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2019 | Office worktables dimensional and mechanical durability requirements | |
| EN 13986:2004 | Wood-based panels for construction, formaldehyde emission class E1 |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to static load and cycle testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable to material emissions and recyclability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural stability | |
|---|---|---|
| GB/T 3327-2016 | Office desk performance test methods, applicable to load and durability validation | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood products, E1 grade requirement |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural stability; 2. GB/T 3327-2016: Office desk performance test methods, applicable to load and durability validation; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood products, E1 grade requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
