Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 3200 x 1100 x 760 mm | |
|---|---|---|
| Matching hutch overall dimensions | 3200 x 450 x 2200 mm | |
| Desktop panel thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Central knee well width | 1200 mm | |
| Knee well height under desktop | 620 mm | |
| Knee well depth | 550 mm | |
| Left/right pedestal width per side | 1000 mm | |
| Pedestal storage drawer internal height | 150 mm | |
| Hutch open shelf height | 350 mm | |
| Hutch glass-front cabinet internal depth | 400 mm | |
| Desk modesty panel thickness | 25 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 200 kg | |
|---|---|---|
| Drawer slide open/close cycle rating | 50000 cycles | |
| Desk net weight (without hutch) | 260 kg | |
| Maximum seated user weight capacity | 150 kg | |
| Finish scratch resistance rating | 3H | |
| Standard commercial product warranty | 20 years | |
| Drawer slide static load rating | 45 kg | |
| Hinge open/close cycle rating | 80000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | High-density engineered wood core with 0.6mm hardwood veneer | |
|---|---|---|
| Desktop finish | 12-layer high-gloss polished nitrocellulose lacquer | |
| Pedestal frame and panels | Solid hardwood carved frame with veneered MDF panel infill | |
| Modesty panel | Veneered MDF with carved edge molding | |
| Hutch frame and doors | Solid hardwood frame with veneered panels, 5mm clear tempered glass for glass-front cabinets | |
| Drawer boxes | 12mm thick solid birch plywood with dovetail joints | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Door hinges | Brushed nickel-plated steel soft-close concealed hinges | |
| Desk leg/base feet | Solid carved hardwood with decorative molded foot caps | |
| Cable grommets | Brushed zinc alloy, finish matched to desk hardware | |
| Edge trim and carvings | Hand-carved solid hardwood appliques with matching lacquer finish | |
| Shelf surfaces (hutch) | Veneered MDF with sealed edge banding |
Adjustment / rotation / tilt / mobility / storage features
| Left pedestal storage | 3 locking drawers (2 stationery, 1 hanging file) with full-extension slides | |
|---|---|---|
| Right pedestal storage | 1 locking drawer stack + 1 enclosed cabinet with adjustable shelf | |
| Hutch storage layout | 3 open display shelves, 2 glass-front display cabinets, 4 solid-door enclosed storage cabinets | |
| Cable management | 2 dual-port cable grommets on desktop, integrated under-desk metal cable tray | |
| Drawer locking system | Centralized key lock secures all pedestal drawers on each side | |
| Hutch shelf adjustability | Open and enclosed cabinet shelves have 50mm incremental height adjustment | |
| Door operation | Hutch cabinet doors open 110 degrees with soft-close damping | |
| Knee clearance access | Central open recess provides unobstructed leg access for seated executive users | |
| Surface protection | High-gloss lacquer finish resists water rings and common office stains | |
| Installation type | Freestanding desk, wall-anchored hutch for stability | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Formal dedicated office space for C-suite leadership, supports document storage and professional meetings | |
|---|---|---|
| Corporate boardroom ancillary workspace | Adjacent to meeting rooms for executive prep work and secure document storage | |
| Government official office | Formal traditional office environment requiring high-capacity locked storage and dignified aesthetic | |
| Law firm partner office | Secure file storage for sensitive legal documents and client meeting use | |
| High-end home executive study | Residential luxury home office setups matching traditional interior design schemes | |
| Enterprise reception executive meeting area | Formal greeting space for high-value client visits and small in-office meetings |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements, applicable for commercial office desk performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables, mechanical safety requirements for height-adjustable and fixed desks | |
| EN 13722:2004 | Furniture, strength and durability of storage units, applicable to desk pedestals and hutch | |
| EN 71-3:2019 | Migration of certain elements, applicable for surface finish safety in indoor environments |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood office desk and hutch construction | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior decoration materials, wooden furniture, required for indoor office use | |
| GB/T 4897.3-2011 | Particleboard specifications for furniture use, applicable if engineered wood core is used | |
| GB/T 1931-2009 | Wood moisture content determination method, required for solid wood components to prevent warping |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood office desk and hutch construction; 2. GB 18584-2001: Formaldehyde emission limit for interior decoration materials, wooden furniture, required for indoor office use; 3. GB/T 4897.3-2011: Particleboard specifications for furniture use, applicable if engineered wood core is used; 4. GB/T 1931-2009: Wood moisture content determination method, required for solid wood components to prevent warping; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
