| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 2200 x 760 mm | |
|---|---|---|
| Main work surface depth | 1150 mm | |
| Side return length | 2200 mm | |
| Raised monitor platform height | 120 mm | |
| Under-desk knee clearance height | 650 mm | |
| Knee clearance width | 1200 mm | |
| Desktop panel thickness | 50 mm | |
| Leather-wrapped front panel thickness | 30 mm | |
| Side return storage cabinet depth | 600 mm | |
| Edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Support panel wall thickness | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 250 kg | |
|---|---|---|
| Drawer slide load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Unit net weight | 220 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 25mm high-density E0-grade MDF | |
|---|---|---|
| Desktop finish | Matte dark walnut open-pore wood veneer | |
| Front/return cabinet panels | 1.2mm thick full-grain PU leather wrapping | |
| Support structure | Solid MDF panel supports with matte black lacquer finish | |
| Edge treatment | 2mm thick ABS edge banding matched to veneer finish | |
| Storage hardware | Soft-close drawer slides with matte black metal finish | |
| Internal cabinet shelving | 18mm thick MDF with matching veneer finish | |
| Cable management components | ABS plastic grommets with brushed metal trim | |
| Base leveling feet | Nylon adjustable feet with 15mm adjustment range | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Fixed L-shaped layout | Permanent right-side return cabinet forming L workstation | |
|---|---|---|
| Integrated raised monitor platform | Elevated right-side platform for monitor placement to optimize ergonomic viewing | |
| Enclosed side return storage | Soft-close drawer and cabinet storage in side return for office documents | |
| Built-in cable management | Under-desk cable tray and desktop grommets to route power and data cords | |
| Leveling adjustment | Adjustable feet to compensate for uneven office flooring | |
| Stain-resistant surface | Matte and leather finishes resist common office liquid spills and stains | |
| Modular attachment compatibility | Designed to connect with matching back wall storage cabinets for full office suite | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private CEO/president office | Suitable for senior executive private offices with premium design requirements | |
|---|---|---|
| Corporate boardroom adjunct space | Works as a primary workstation attached to formal meeting spaces | |
| High-end law/finance firm offices | Matches professional, sophisticated aesthetic for client-facing executive spaces | |
| Luxury commercial office suites | Compatible with matching wall storage units for full office furnishing packages | |
| Private home executive office | Suitable for high-end residential workspaces requiring commercial-grade furniture |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables dimensional and safety requirements, applicable for ergonomic clearanceAcceptance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic reference for seated desk work surface heights | |
| EN 15372:2016 | Durability and stability requirements for non-domestic office tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Sustainability standard for office furniture material emissions and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for structural qualityAcceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E0 grade substrateAcceptance | |
| GB/T 4897.3-2003 | Requirements for MDF panels used in furniture construction, applicable for substrate quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for structural qualityAcceptance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E0 grade substrateAcceptance; 3. GB/T 4897.3-2003: Requirements for MDF panels used in furniture construction, applicable for substrate quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
