Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 2100 x 750 mm | |
|---|---|---|
| Main worktop depth | 1000 mm | |
| Left return worktop depth | 600 mm | |
| Central knee clearance height | 600 mm | |
| Central knee clearance width | 800 mm | |
| Worktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Pedestal plinth height | 50 mm | |
| Integrated cable channel width | 200 mm | |
| Drawer front panel height | 150 mm | |
| Return cabinet width | 1200 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static uniform load | 150 kg | |
|---|---|---|
| Drawer slide dynamic load rating | 40 kg | |
| Drawer slide cycle rating | 50000 operations | |
| Cabinet hinge cycle rating | 80000 operations | |
| Cable tray static load capacity | 5 kg | |
| Net product weight | 180 kg | |
| Recommended user weight capacity | 150 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core | 25 mm high-density particleboard core | |
|---|---|---|
| Worktop surface | 0.6 mm wood veneer with matte polyurethane coating | |
| Worktop edge | Solid wood beveled edge matching veneer finish | |
| Left return cabinet panel | 18 mm MDF panel with dark brown matte lacquer finish | |
| Cabinet end caps | 1.2 mm brushed stainless steel cladding panels | |
| Central modesty panel | Brushed bronze metal accent panel with integrated ambient light strip | |
| Internal support frame | 10 mm thick steel square tube cross-bracing | |
| Plinth base feet | 2 mm thick brushed stainless steel leveling feet | |
| Drawer hardware | Cold-rolled steel full-extension ball-bearing slides with keyed locks | |
| Cable channel cover | Soft-touch black ABS plastic access panel | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Left return storage cabinet | 2 lockable utility drawers and 1 hanging file drawer with full extension slides | |
|---|---|---|
| Right side storage cabinet | 1 lockable storage compartment for office supplies and personal items | |
| Integrated desktop cable management | Recessed center channel with removable cover routes power and data cables | |
| Leveling adjustment | 4 adjustable stainless steel feet correct uneven floor surfaces up to 15 mm | |
| Ambient accent lighting | Integrated warm-white LED strip along modesty panel edge for under-desk illumination | |
| Drawer locking mechanism | Keyed alike lock system secures all storage drawers and cabinet doors | |
| Cable pass-through | 80 mm diameter grommets route cables from channel to under-desk space | |
| Work surface use | Dual-zone layout supports primary computer work on main top and auxiliary tasks on return | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Serves as primary work surface for CEO, director or senior manager private workspaces | |
|---|---|---|
| Corporate management suite | Matches luxury contemporary office interiors for high-level corporate work areas | |
| Home office executive setup | Provides professional-grade storage and work surface for premium residential offices | |
| Conference breakout room | Functions as a dedicated leader work station in high-end meeting spaces | |
| Recommended seating pair | Pairs with high-back ergonomic executive chairs with 700 mm maximum seat width | |
| Recommended accessory pair | Pairs with under-desk mobile pedestals and monitor arms for ergonomic setup |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office desk dimensional, safety and strength performance requirements | |
|---|---|---|
| EN 15372:2016 | Applies to furniture strength, durability and safety for non-domestic office desks | |
| EN 12521:2015 | Applies to furniture mechanical safety requirements for freestanding office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products strength, durability and stability performance testing | |
|---|---|---|
| ANSI/BIFMA X7.1-2022 | Applies to formaldehyde and VOC emission standards for office furniture components |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, structural and stability requirements for desk products | |
|---|---|---|
| GB/T 4897.3-2003 | Applies to particleboard panel material performance requirements for furniture use | |
| GB 18580-2017 | Applies to formaldehyde emission limits for wood-based panel furniture components |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, structural and stability requirements for desk products; 2. GB/T 4897.3-2003: Applies to particleboard panel material performance requirements for furniture use; 3. GB 18580-2017: Applies to formaldehyde emission limits for wood-based panel furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
