Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desk net weight | 280 kg | |
|---|---|---|
| Desktop static load capacity | 150 kg | |
| Suitable user count | 1 person | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop surface | High-gloss tempered glass with polished edge trim | |
|---|---|---|
| Front modesty panel | Brushed stainless steel with vertical ribbed texture | |
| Left support leg | High-gloss black lacquered engineered wood with chrome trim | |
| Right support pedestal | Brushed stainless steel cylindrical solid base | |
| Frame substrate | High-density MDF core with lacquer finish | |
| Back credenza cabinet doors | Matte lacquered engineered wood with metal frame trim | |
| Back credenza open shelves | Tempered glass shelves with integrated LED strip lighting | |
| Hardware components | Zinc alloy soft-close drawer glides and hinges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated cable management | Concealed under-desk cable tray with desk-top grommets for wire routing | |
|---|---|---|
| Side storage drawers | 3 soft-closing lockable storage drawers in side return for document storage | |
| Back credenza storage | Combination of closed cabinets, open display shelves and hanging file compartment | |
| Ergonomic working height | Fixed 750 mm working height matching standard office chair seat height | |
| Modesty panel privacy | Full-height front ribbed panel blocking direct view of under-desk leg area | |
| Leveling feet | Adjustable stainless steel leveling feet on all support points for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for C-suite and senior management private office spaces, matching high-end corporate decor | |
|---|---|---|
| High-end boardroom support space | Usable as a principal work surface in large executive meeting or preparation rooms | |
| Luxury home office | Applicable to high-end residential home offices for professionals requiring premium workspace | |
| VIP reception office area | Suitable for corporate VIP reception offices that host high-value client meetings |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions | |
|---|---|---|
| EN 527-2:2002 | Office furniture - Work tables and desks - Part 2: Safety requirements | |
| EN 13722:2004 | Office furniture - Storage units - Requirements and test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for performance, durability and structural adequacy | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Tests for performance, durability and structural adequacy |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks and tables | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances in wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3327-2017: Performance requirements for office desks and tables; 3. GB 18584-2001: Indoor decoration material limit of harmful substances in wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
