Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (closed position) | 1200 x 610 x 485 mm | |
|---|---|---|
| Lifted tabletop height | 545 mm | |
| Lift mechanism vertical stroke | 140 mm | |
| Tabletop panel thickness | 18 mm | |
| Under-base floor clearance | 40 mm | |
| Hidden storage compartment internal height | 180 mm | |
| Rounded corner radius (all exposed edges) | 30 mm | |
| Central fluted front panel width | 600 mm | |
| Side cabinet door width per panel | 250 mm | |
| Base side panel thickness | 15 mm | |
| Foot support height | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net product weight | 25 kg | |
|---|---|---|
| Total static distributed load capacity | 30 kg | |
| Lifted tabletop maximum static load | 10 kg | |
| Hidden storage compartment maximum load | 10 kg | |
| Recommended maximum user weight for lifted work surface use | 100 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Lift mechanism rated service cycles | 10000 operations | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Lift tabletop substrate | 18mm thick MDF core | |
|---|---|---|
| Tabletop surface finish | Herringbone-pattern natural oak wood veneer, matte sealant topcoat | |
| Base cabinet structure | 15mm thick particleboard/E0-grade engineered wood | |
| Base exterior finish | Matte light gray PU paint, smooth scratch-resistant coating | |
| Central front panel | Vertical fluted engineered wood panel, matching light gray finish | |
| Lift mechanism hardware | 1.5mm thick cold-rolled steel hinge assembly, powder-coated black | |
| Support feet | High-density PP plastic, non-marking floor protection pads | |
| Door hinges | Concealed soft-close steel cabinet hinges, nickel-plated finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Lift-top height adjustment | Spring-assisted metal mechanism lifts and locks top to 60mm extended height for work/dining use | |
|---|---|---|
| Hidden under-top storage | Enclosed compartment under lift top stores remotes, magazines, and small living room items | |
| Side cabinet storage | Two right-side hinged doors provide enclosed storage for larger items, no visible external handles | |
| Soft-close mechanism | Integrated soft-close damper prevents slamming when lowering lift top and closing cabinet doors | |
| Under-base clearance access | 40mm floor clearance allows most robot vacuums to pass under the table for easy cleaning | |
| Rounded edge safety design | All exposed top and base corners feature rounded profiles to reduce impact injury risk | |
| Surface maintenance | Matte sealed surface is stain-resistant and wipeable for everyday spill cleanup | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Centered in front of sofas for beverage service, remote storage, and occasional laptop work | |
|---|---|---|
| Small apartment multi-use space | Lifted top converts to casual dining or work surface to save separate furniture space | |
| Modern contemporary interior schemes | Matches light neutral and warm wood tone palettes, fluted detailing fits current design trends | |
| Family household use | Rounded safety edges reduce injury risk for children and pets in active home environments |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable for structural performance testing | |
|---|---|---|
| EN 312:2010 | Particleboard – Specifications, applicable for engineered wood base panel structural performance | |
| EN 13722:2004 | Furniture – Test methods for surface resistance to cold liquids |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety and dimensional tolerances | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing | |
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable for base panel material performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety and dimensional tolerances; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing; 3. GB/T 4897.3-2015: Particleboard for furniture use, applicable for base panel material performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
