Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3200 × 1820 × 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Seated knee clearance height under desktop | 620 mm | |
| Knee clearance width at user position | 850 mm | |
| Open under-desk shelf depth | 350 mm | |
| Edge band thickness on desktop | 2 mm | |
| Sculpted left support panel thickness | 36 mm | |
| Cable grommet inner diameter (desktop) | 60 mm | |
| Side base cable port diameter | 80 mm | |
| Right side storage cabinet height | 640 mm | |
| Desktop overhang at front edge | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static uniform load capacity | 100 kg | |
|---|---|---|
| Finish abrasion resistance cycles | 1000 cycles | |
| Recommended maximum user weight accommodation | 136 kg | |
| Product net weight (reference) | 150 kg | |
| Available finish color options | 4 | |
| Manufacturing defect warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | E1 grade medium-density fiberboard (MDF) | |
|---|---|---|
| Desktop surface | 0.6 mm thick light oak wood veneer with matte clear lacquer | |
| Desktop edge trim | 2 mm thick matching PVC edge banding | |
| Sculpted base and cabinet | E1 grade MDF substrate with off-white matte polyurethane lacquer | |
| Left support perforated detail | Laser-cut decorative dot pattern on painted MDF panel | |
| Open under-desk shelf surface | Matching light oak veneer finish on MDF panel | |
| Cable grommet inserts | Brushed zinc alloy | |
| Structural connecting hardware | Nickel-plated steel bolts and cam locks | |
| Base leveling feet | Reinforced nylon adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Desktop cable access cutout | Dual grommet positions for power and data cable routing | |
|---|---|---|
| Side base cable pass-through port | Integrated rear port for routing cables to floor outlets | |
| Open under-desk storage shelf | Recessed fixed shelf for document and accessory storage | |
| Right integrated base cabinet | Enclosed curved storage compartment for office supplies | |
| Adjustable base leveling | 15 mm adjustment range on hidden glides to stabilize desk on uneven floors | |
| Seated work position orientation | Single central user position facing long desktop edge | |
| Surface easy-clean performance | Stain-resistant matte finish for wipe cleaning of spills | |
| Knock-down assembly design | Flat-packed components for on-site assembly with included hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Large size and premium finish suit CEO/management private workspace | |
|---|---|---|
| High-end home office | Designer silhouette fits luxury residential work-from-home spaces | |
| Corporate boardroom auxiliary desk | Wide surface supports meeting material and presentation device placement | |
| Professional reception manager office | Stylish appearance balances professionalism and modern aesthetic | |
| Recommended pairing | Matches high-back light-colored leather executive office chairs for cohesive style | |
| Cable management use case | Dual cable ports support desktop monitor, laptop and office device power routing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial office use | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional requirements for seated work, applicable for ergonomic fit | |
| EN 13722:2004 | Furniture test methods for surface resistance to abrasion, applicable for finish durability |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desk structural integrity | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, recommended for indoor air quality acceptance | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable for engineered wood substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desk structural integrity; 2. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, recommended for indoor air quality acceptance; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable for engineered wood substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
