Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3200 × 2000 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Side cabinet drawer static load per drawer | 30 kg | |
| Set net weight (desk + chair + credenza) | 380 kg | |
| Recommended maximum user weight for chair | 150 kg | |
| Design service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main desktop surface | Engineered wood with walnut grain veneer, matte scratch-resistant finish | |
|---|---|---|
| Desk base and cabinet panels | High-density MDF with two-tone light beige matte lacquer | |
| Decorative trim | Brushed champagne gold plated metal alloy, 10mm wide profile | |
| Executive chair upholstery | Top-grain match leather with vertical stitched channel detailing | |
| Chair internal frame | 1.8mm thick welded steel tube, anti-corrosion powder coating | |
| Storage cabinet hinges and slides | Cold-rolled steel soft-close hardware, zinc plated finish | |
| Integrated shelving lighting | 24V LED strip lights, 4000K neutral white, recessed into shelf undersides | |
| Floor glides | Adjustable nylon glide feet, 20mm adjustment range | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | Recessed cable ports on desktop surface with under-desk routing channel | |
|---|---|---|
| Side return storage | Fixed cabinet with two soft-closing drawers for document and supply storage | |
| Rear credenza storage zones | Built-in hanging wardrobe compartment, 4 open display shelves, 1 tambour door cabinet, side wine display shelf | |
| Executive chair adjustability | 360-degree swivel, 100mm gas lift height adjustment, 15-degree recline backrest with lock | |
| Accent lighting system | Touch-controlled LED strip lighting for all display shelves, low voltage power supply | |
| Leveling adjustment | Individual adjustable glides on all cabinet and desk supports for uneven floor compensation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Designed for C-suite and senior management private offices in corporate headquarters, supports computer work and small meetings | |
|---|---|---|
| High-end reception meeting area | Suitable for boardroom anterooms and executive reception spaces to present a professional premium brand image | |
| Boutique professional firm office | Appropriate for law firms, investment firms and consulting offices where professional image and durable function are required | |
| Luxury home office | Suitable for high-end residential home office spaces for executives who work remotely, integrated storage reduces clutter |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to desk structural testing | |
|---|---|---|
| EN 1335-1:2020 | Office chairs dimensions and safety requirements, applicable to matching executive chair | |
| EN 14749:2016 | Domestic and kitchen storage units safety requirements, applicable to rear credenza |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Office chairs general purpose safety and performance standard, applicable to included executive chair | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to executive desk load and stability testing |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and cabinet panels and finishes | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks, applicable to load capacity and structural stability | |
| GB/T 3325-2017 | Hardware performance requirements for furniture, applicable to drawer slides and hinges | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing for wood panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and cabinet panels and finishes; 2. GB/T 3327-2017: Performance requirements for office desks, applicable to load capacity and structural stability; 3. GB/T 3325-2017: Hardware performance requirements for furniture, applicable to drawer slides and hinges; 4. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing for wood panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
