Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 2050 x 760 mm | |
|---|---|---|
| Main work surface depth | 1000 mm | |
| Desktop thickness | 65 mm | |
| Knee clearance height under desktop | 650 mm | |
| Knee clearance width | 1200 mm | |
| Side return worktop depth | 600 mm | |
| Side return cabinet height | 580 mm | |
| Fluted front panel slat width | 20 mm | |
| Edge banding thickness | 2 mm | |
| Embedded power grommet size | 160 x 80 mm | |
| Rounded cabinet corner radius | 150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed desktop static load capacity | 150 kg | |
|---|---|---|
| Single drawer slide load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Net weight (desk unit) | 150 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user count | 1 | |
| Product warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | High-density MDF core | |
|---|---|---|
| Work surface finish | 0.6 mm walnut wood veneer with water-based matte paint | |
| Edge banding | Solid walnut wood beveled edge, 2 mm thickness | |
| Fluted front panels | Beige painted MDF vertical slats | |
| Cabinet body structure | 18 mm thick plywood cabinet panels | |
| Hardware components | Cold-rolled steel soft-close drawer slides and hinges | |
| Ambient lighting | 24V LED strip light with frosted diffuser | |
| Power module | ABS shell multimedia unit with power outlets and USB ports | |
| Base plinth | Powder-coated light beige steel trim | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Central seated knee opening | Provides 650 mm clearance height for ergonomic executive chair use | |
|---|---|---|
| Left side storage return | Integrated cabinet with open/closed storage for files and CPU storage | |
| Embedded desktop power module | Integrated AC power and USB charging ports for device connectivity | |
| Integrated ambient LED lighting | Warm white strip along front fluted panel for office ambiance | |
| Side return control panel | Embedded touch panel for LED and desk function adjustment | |
| Under-desk cable management | Removable cable tray with grommet routing for wire organization | |
| Soft-close storage hardware | Self-closing drawer and door mechanisms to reduce operating noise | |
| Rounded safety corners | Soft radius cabinet edges to reduce impact injury risk | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for president, director and senior management private workspaces | |
|---|---|---|
| Corporate headquarters | Ideal for high-end corporate office environments requiring premium furnishing | |
| High-end home office | Suitable for luxury residential workspaces with executive functional requirements | |
| Boardroom ancillary space | Can be used for executive meeting preparation rooms adjacent to board areas | |
| Recommended matching furniture | Pairs with high-back ergonomic leather executive chairs and matching wood bookshelves | |
| Recommended floor protection | Used with low-pile office area rugs to protect hard flooring |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for European market acceptance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and safety requirements, applicable for ergonomic compliance | |
| EN 13722:2004 | Furniture strength and durability for storage units, applicable for cabinet validation |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for North American market load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality acceptance | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks, applicable for load and stability verification | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing | |
| GB/T 4897.3-2003 | Particleboard/MDF requirements for furniture use, applicable for substrate quality verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality acceptance; 2. GB/T 3327-2017: Performance requirements for office desks, applicable for load and stability verification; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing; 4. GB/T 4897.3-2003: Particleboard/MDF requirements for furniture use, applicable for substrate quality verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
