Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1100 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 180 kg | |
|---|---|---|
| Static work surface load capacity | 150 kg | |
| Recommended user count | 1 person | |
| Surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 10 N·m | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | 18mm E0-grade particleboard | |
|---|---|---|
| Work surface finish | Walnut wood veneer with matte PU coating | |
| Side pedestal facade | Fluted light taupe engineered wood panels | |
| Front modesty panel | 25mm walnut-veneer MDF with accent inlay strips | |
| Structural support frame | 1.5mm thick cold-rolled steel internal frame | |
| Cable grommet | ABS plastic recessed port | |
| Edge banding | 2mm thick matching PVC edge trim | |
| Leveling feet | Nylon adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management grommet | Recessed desktop port routes power/data cables below work surface | |
|---|---|---|
| Seated knee access | Central open bay accommodates executive office chairs with full leg extension | |
| Floor leveling adjustment | Adjustable base glides compensate for 15mm floor unevenness | |
| Work surface zoning | Left section for device placement, central writing zone, right section for documents | |
| Freestanding installation | No wall mounting required, fully self-supporting on floor glides | |
| Surface stain resistance | Matte coating resists common office liquid spills for easy cleaning | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Serves as primary workstation for C-suite and senior management | |
|---|---|---|
| Corporate boardroom ancillary space | Functions as meeting leader desk for small in-room discussions | |
| High-end home office | Fits luxury residential workspaces with classic modern interior design | |
| Corporate reception executive area | Provides formal workspace for senior client-facing staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for dimensional and safety requirements of office work desks | |
|---|---|---|
| EN 527-2:2016 | Applicable for mechanical safety and stability requirements for office desks | |
| EN 13722:2004 | Applicable for surface resistance requirements for office furniture |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Applicable for formaldehyde emission limits of wood-based panel products | |
| GB/T 4897.3-2003 | Applicable for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB 18580-2017: Applicable for formaldehyde emission limits of wood-based panel products; 3. GB/T 4897.3-2003: Applicable for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
