Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2200 x 1800 x 750 mm | |
|---|---|---|
| Main desktop thickness | 50 mm | |
| PVC edge banding thickness | 2 mm | |
| Main work surface depth | 900 mm | |
| Right return cabinet depth | 580 mm | |
| Right return cabinet length | 1800 mm | |
| Seated knee clearance height | 650 mm | |
| Seated knee clearance width | 700 mm | |
| Modesty panel height | 400 mm | |
| Steel leg wall thickness | 2 mm | |
| Desktop cable grommet diameter | 76 mm | |
| Leveling glide adjustment height | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Net product weight | 125 kg | |
| Recommended user capacity | 1 person | |
| Melamine finish abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main work surface | E1 grade melamine-faced particle board, light wood-tone matte finish | |
|---|---|---|
| Storage cabinet panels | E1 grade melamine-faced particle board, charcoal black matte finish | |
| Front modesty panel | E1 grade melamine-faced particle board, charcoal black finish | |
| Support legs | Powder-coated black steel with polished chrome foot accents, angled profile | |
| Desktop edging | 2mm thick PVC edge banding with 45° beveled profile | |
| Internal support frame | Square steel cross-bracing under desktop for structural rigidity | |
| Cabinet hardware | Cold-rolled steel drawer slides and hinges with black finish | |
| Cable grommets | ABS plastic flip-top cable pass-through with brush seal | |
| Floor glides | Nylon base with adjustable threaded steel stem | |
| Cable access vents | ABS plastic vented panel on return cabinet side | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Dual access: desktop flip grommet and side cabinet vent, with under-desk cable tray | |
|---|---|---|
| Fixed right-side storage return | Integral cabinet with 2 drawers, 1 hinged door compartment and open CPU shelf | |
| Floor leveling adjustment | Threaded glides on each leg adjust up to 15mm to stabilize desk on uneven floors | |
| Privacy modesty panel | Fixed front panel blocks view of user legs from front office approach | |
| Storage drawer operation | Soft-close full-extension drawer slides for smooth access to stored office supplies | |
| Cabinet door operation | 110° opening hinge with soft-close mechanism for enclosed storage access | |
| Work surface configuration | L-shaped layout provides separate main work zone and secondary meeting/document zone | |
| Assembly structure | Knock-down flat-pack construction with cam-lock and bolt fasteners for on-site assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for manager, director or CEO private office spaces, provides professional work surface and storage | |
|---|---|---|
| Open office manager workstation | Deployable as senior staff workstation in open-plan office layouts with dedicated personal storage | |
| Small conference meeting space | Secondary return surface supports small 3person impromptu meetings at the desk | |
| Home office executive setup | Applicable for high-end home offices requiring commercial-grade durability and storage | |
| Recommended pairing | Pairs with high-back ergonomic executive chair and lateral filing cabinet for complete office setup | |
| Cable-dependent work setup | Integrated cable management supports multi-monitor, laptop and office phone configurations |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables: safety and strength requirements for commercial desk performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables: dimensional requirements for ergonomic seated work surfaces | |
| EN 12521:2015 | Furniture: strength, durability and safety requirements for non-domestic seating-adjacent tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products: performance and safety standard for commercial office desk testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units: performance requirements for integrated desk return cabinet components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and cabinet construction | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks, applicable to strength, stability and dimensional checks | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to E1 grade panel substrate verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and cabinet construction; 2. GB/T 3327-2017: Performance requirements for office desks, applicable to strength, stability and dimensional checks; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to E1 grade panel substrate verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
