Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (extended) | 2800 x 400 x 500 mm | |
|---|---|---|
| Closed overall width | 2000 mm | |
| Plinth base ground clearance | 150 mm | |
| Left enclosed storage compartment width | 1200 mm | |
| Cantilevered sliding top extension travel | 800 mm | |
| Tapered right end panel angle | 75 degrees | |
| Top panel thickness | 18 mm | |
| Carcass side panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Decorative lattice inlay size | 120 x 60 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total unit net weight | 52 kg | |
|---|---|---|
| Total top surface static load capacity | 162 kg | |
| Maximum supported TV screen size | 100 in | |
| Sliding top mechanism cycle rating | 10000 cycles | |
| Surface scratch resistance rating | 2B | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural carcass panels | 18mm E0-grade high-density fiberboard | |
|---|---|---|
| Top surface veneer | Dark walnut wood veneer with matte scratch-resistant lacquer | |
| Side panel finish | Matte dark grey hard-wearing lacquer | |
| Back panel | 9mm HDF with ventilation cutouts | |
| Left side decorative inlay | Laser-cut geometric lattice wood inlay | |
| Sliding mechanism hardware | Cold-rolled steel telescopic glides with soft-close damping | |
| Plinth base | Engineered wood with matching walnut edge trim, stepped recessed design | |
| Internal shelf (enclosed compartment) | 18mm HDF with matching veneer finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Single-side cantilever sliding top | Slides horizontally 800mm to adjust total width for variable TV sizes | |
|---|---|---|
| Enclosed left storage bay | Concealed compartment for media devices, accessories and cable management | |
| Soft-close sliding mechanism | Damped glides prevent slamming and ensure smooth, quiet extension travel | |
| Recessed plinth base | Elevates unit 150mm for floor clearance and concealed under-unit cable routing | |
| Decorative lattice vent panel | Provides passive ventilation for enclosed AV equipment to prevent overheating | |
| Cable management openings | Pre-drilled 60mm diameter cutouts in back panel for AV cord routing | |
| Anti-tip anchoring | Wall anchor hardware included to secure unit for safety with large screen TVs | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Modern residential living rooms | Fits low-profile media setups against main viewing walls for large screen TVs | |
|---|---|---|
| Minimalist home theater spaces | Conceals AV equipment while providing ventilation and cable management | |
| Open-plan contemporary apartments | Asymmetric cantilever silhouette serves as a design feature alongside functional media use | |
| Executive lounge reception areas | Provides media storage for presentation screens with sleek, professional dark finish |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard and fiberboard performance specifications for structural use | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E0 grade compliance reference | |
| GB/T 4893.4-2013 | Surface film adhesion and scratch resistance test for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E0 grade compliance reference; 3. GB/T 4893.4-2013: Surface film adhesion and scratch resistance test for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
