Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 3000 x 2200 x 760 mm | |
|---|---|---|
| Main work surface depth | 1000 mm | |
| Side return length | 1800 mm | |
| Work surface thickness | 50 mm | |
| Knee clearance width | 700 mm | |
| Knee clearance height | 650 mm | |
| Plinth base height | 110 mm | |
| Leather writing pad width | 1800 mm | |
| Leather writing pad depth | 400 mm | |
| Apron carved trim thickness | 30 mm | |
| Central carved medallion diameter | 350 mm | |
| Edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for storage doors | 80000 cycles | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended maximum user weight | 150 kg | |
| Product net weight | 400 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work top core | Solid hardwood, polished brown lacquer finish | |
|---|---|---|
| Front modesty panel | Carved solid wood, central openwork circular medallion | |
| Plinth base | Solid wood frame, mortise and tenon joinery | |
| Writing surface pad | Top-grain brown leather, stitched edge | |
| Drawer sides and internals | Solid hardwood, dovetail joinery | |
| Drawer slides | Cold-rolled steel, three-quarter extension | |
| Door hinges | Brass-finish steel, soft-close mechanism | |
| Cable grommets | Brushed brass metal, flush fit | |
| Edge trim | Solid wood matching worktop, carved profile | |
| Finish coat | Nitrocellulose lacquer, semi-gloss sheen | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| L-shaped work layout | Left-side return provides auxiliary work surface for visitor seating or document layout | |
|---|---|---|
| Central storage drawers | Three pencil/box drawers and two file drawers integrated under main work surface | |
| Return cabinet storage | Two-door closed cabinet on side return for office supplies and files | |
| Cable management | Two desk-top grommets route power and data cables to under-desk tray | |
| Floor leveling | Integral plinth base provides stable floor contact without adjustable glides | |
| Removable writing pad | Leather desk pad can be lifted for cleaning or surface access | |
| Modesty panel privacy | Full-height carved front panel blocks knee visibility from office entry | |
| Weight distribution | Wide plinth base spreads load evenly to prevent floor indentation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Fits CEO/president private offices as primary formal work surface | |
|---|---|---|
| Corporate board side office | Suitable for senior manager offices requiring formal traditional aesthetic | |
| Government/agency office | Works for official formal office spaces requiring traditional solid wood furniture | |
| Paired furniture set | Coordinates with matching leather executive chair and wood display bookcase | |
| Visitor meeting use | Side return provides space for 3visitor seats across the desk | |
| High-end commercial office | Suitable for premium class-A office buildings with luxury fit-out specifications |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks, Part 1: Dimensions, applicable for ergonomic dimensional compliance | |
|---|---|---|
| EN 527-2:2002+A1:2006 | Office furniture - Work tables and desks, Part 2: Mechanical safety requirements, applicable for structural stability checks | |
| EN 1335-1:2020 | Office furniture - Office work chairs, referenced for ergonomic fit with seated work height |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products, applicable for structural performance and durability testing benchmarks | |
|---|---|---|
| ANSI/BIFMA e3-2020 | Furniture Sustainability Standard, applicable for material emission and sustainability evaluation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality acceptance | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables, applicable for dimensional and performance requirement verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, applicable for formaldehyde and VOC emission checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality acceptance; 2. GB/T 3327-2016: Office desks and tables, applicable for dimensional and performance requirement verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, applicable for formaldehyde and VOC emission checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
