Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2400 x 1800 x 760 mm | |
|---|---|---|
| Main worktop thickness | 50 mm | |
| Main worktop usable depth | 800 mm | |
| Side return length | 1800 mm | |
| Side return depth | 500 mm | |
| Under-desk knee clearance height | 650 mm | |
| Under-desk knee clearance width | 1200 mm | |
| Cable grommet port dimensions | 60 x 240 mm | |
| Edge band thickness | 3 mm | |
| Modesty panel height | 550 mm | |
| Side return cabinet height | 650 mm | |
| Base support panel thickness | 36 mm | |
| Adjustable glide height adjustment | 25 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet door hinge cycle rating | 80000 cycles | |
| Net product weight | 115 kg | |
| Recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop construction | E1 grade particleboard core with light oak effect melamine laminate | |
|---|---|---|
| Base and cabinet panels | E1 grade MDF core with matte cream melamine finish | |
| Edge detailing | 3mm thick PVC edge banding with rounded radius corners | |
| Hardware components | Zinc-plated steel cam locks, screws, and adjustable nylon glides | |
| Cable grommet cover | Matte black ABS plastic with integrated brush seal | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustability | Fixed 760mm worktop height, no electric or manual height adjustment | |
|---|---|---|
| Cable management | Rectangular worktop grommet with under-desk cable routing to keep cords organized | |
| Storage configuration | Left-side fixed enclosed storage credenza for files and office supplies | |
| Assembly orientation | Non-reversible left-side return, cannot be reconfigured for right-side installation |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Provides generous work surface and integrated storage for senior management workspaces | |
|---|---|---|
| Home office study | Two-tone contemporary finish fits residential interiors while offering commercial-grade functionality |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for structural performance testing | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional, mechanical and durability requirements, applicable for ergonomic clearance checks | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to side return cabinet performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for static load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable for side return cabinet load and cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for structural safety and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to worktop core material performance requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for structural safety and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to worktop core material performance requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
