Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1500 x 760 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Modesty panel height | 620 mm | |
| Pedestal base width | 300 mm | |
| Central power strip cutout size | 2000 x 100 mm | |
| Seated knee clearance height | 660 mm | |
| Edge chamfer radius | 15 mm | |
| Leveler foot height adjustment | 12 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 170 kg | |
|---|---|---|
| Tabletop uniform static load capacity | 500 kg | |
| Seating capacity | 12 people | |
| Surface scratch resistance rating | 3H | |
| Wood substrate moisture content | 12% | |
| Power module port count | 6 | |
| Product warranty | 18 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High-density MDF with 780 kg/m³ density | |
|---|---|---|
| Tabletop finish | AAA grade walnut wood veneer with 8-coat polyester lacquer | |
| Edge banding | 2 mm thick solid walnut edge trim | |
| Pedestal structure | Engineered wood box frame with dark bronze metal trim accents | |
| Modesty panel | 18 mm thick walnut-veneer engineered wood panel | |
| Leveler feet | Zinc alloy adjustable glides with nylon contact pads | |
| Cable management channel | ABS plastic recessed trough with brushed metal flip covers | |
| Hardware connectors | Zinc-plated steel cam lock and bolt fasteners | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management | Recessed under-table trough routes cables from floor to tabletop ports | |
|---|---|---|
| Integrated power access | Flip-top covers provide access to AC and USB charging ports for all seated participants | |
| Floor leveling | Adjustable glides at each pedestal foot correct for uneven carpet or hard flooring | |
| Two-sided seating layout | Symmetrical design supports equal seating access on both long table sides | |
| Stain-resistant surface | Non-porous lacquer finish allows wiping of coffee, ink and liquid spills without staining | |
| Knockdown assembly | Table ships in flat sections for on-site assembly without specialized lifting equipment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Large corporate conference room | Seats 12 participants for team meetings, training sessions, and cross-department collaboration | |
|---|---|---|
| High-end client reception area | Formal appearance supports high-stakes client meetings and contract signings | |
| Private office meeting zone | Suitable for large executive private offices with dedicated meeting space |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Furniture test for surface resistance to cold liquids | |
| EN 15372:2016 | Office furniture durability requirements for non-domestic seating and tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for low-emission materials |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18584-2001: Limit of harmful substances in wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
