Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2400 x 2250 x 760 mm | |
|---|---|---|
| Main worktop depth | 900 mm | |
| Right-side return length | 2250 mm | |
| Work surface thickness | 38 mm | |
| Edge band thickness | 2 mm | |
| Front knee clearance height | 650 mm | |
| Knee clearance width (central) | 1200 mm | |
| Return cabinet height | 500 mm | |
| Modesty panel thickness | 25 mm | |
| Support leg panel thickness | 50 mm | |
| Cable port diameter | 80 mm | |
| Base plinth height | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 125 kg | |
|---|---|---|
| Drawer dynamic load rating (if equipped) | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating (if doors are equipped) | 100000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Unit net weight (assembled) | 110 kg | |
| Recommended user weight capacity | 136 kg | |
| Leveling glide adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | High-density particleboard (MFC) | |
|---|---|---|
| Worktop finish | Dark wood-grain high-pressure laminate | |
| Cabinet panel finish | Matte off-white thermofused melamine | |
| Edge banding | 2mm thick PVC edge banding | |
| Support structure | Engineered wood solid panel legs | |
| Modesty panel | 25mm thick engineered wood panel | |
| Cable port fitting | Black ABS plastic grommet/cover | |
| Hardware components | Zinc-plated steel cam locks, screws, and connectors | |
| Base plinth trim | Matching dark wood-grain laminate trim | |
| Leveling glides | Reinforced nylon with steel threaded stems | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Fixed right-side storage return | Integrated low cabinet extends perpendicular to main desk | |
|---|---|---|
| Full front modesty panel | Solid panel conceals leg area and under-desk cabling | |
| Integrated cable management port | Pass-through on return cabinet routes cables from floor to desk | |
| Adjustable leveling glides | Rotate to raise/lower corners for uneven office floors | |
| Enclosed storage compartment(s) | Low return cabinet holds files, supplies, and personal items | |
| Dual-height work surface tier | Main desk sits at standard seated work height, return at matching low height | |
| Seamless L-shaped work layout | Continuous surface connects main desk to return without gaps | |
| Scratch-resistant work surface | Laminate finish resists marks from laptops, mugs, and writing tools | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive/manager office | Provides professional work surface and storage for leadership personnel | |
|---|---|---|
| Open-plan manager workstations | Defines a dedicated, private work zone in open office layouts | |
| Home office for remote professionals | Offers ample work space and storage for full-time work-from-home use | |
| Conference side work area | Serves as a supplementary work surface in small meeting rooms | |
| Small business owner workspace | Combines work surface and storage in one footprint for compact offices | |
| Reception back-office area | Provides work space for administrative staff processing visitor documents |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables - Mechanical safety requirements | |
| EN 14372:2004 | Furniture hardware - drawer slides performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Safety and performance standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 17657-2013 | Test methods for wood-based furniture panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 4897.3-2003: Particleboard for furniture use; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 17657-2013: Test methods for wood-based furniture panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
