| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 2400 x 2100 x 768 mm | |
|---|---|---|
| Desktop thickness | 66 mm | |
| Main desktop depth (primary work surface) | 900 mm | |
| Side return cabinet dimensions | 2100 x 600 x 650 mm | |
| Central seated knee clearance height | 650 mm | |
| Central knee clearance width | 1200 mm | |
| Fluted modesty panel height | 400 mm | |
| Cable grommet diameter | 80 mm | |
| Edge band thickness | 2 mm | |
| Support leg panel thickness | 50 mm | |
| Desktop corner radius | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for cabinet doors | 80000 cycles | |
| Desk net weight | 220 kg | |
| Integrated LED strip lifespan | 30000 hours | |
| Surface abrasion resistance rating | 2000 cycles | |
| Seating capacity | 1 person | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary desktop surface | E0-grade MDF substrate with light oak wood grain veneer | |
|---|---|---|
| Cabinet and modesty panel surfaces | E0-grade MDF with off-white matte paint finish | |
| Left pedestal decorative trim | Brass-toned brushed metal inlay with perforated accent detail | |
| Support frame and internal structure | 1.2mm thick cold-rolled steel reinforcing brackets | |
| Modesty panel construction | Vertical fluted engineered wood slats with matte off-white finish | |
| Edge treatment | 2mm thick PVC edge banding matched to desktop finish | |
| Drawer hardware | Three-section silent soft-close cold-rolled steel slide rails | |
| Cabinet hinge hardware | Buffer soft-close cold-rolled steel hinges with nickel plating | |
| Integrated lighting | Low-voltage 24V warm white LED strip embedded in right side panel | |
| Cable management fitting | ABS plastic rotating cable grommet with brush seal | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Central knee bay access | Open unobstructed leg space under main desktop for seated executive use | |
|---|---|---|
| Side return storage | Attached right-side cabinet with combination of drawers and closed storage compartments | |
| Cable management system | Desktop grommet routes power and data cables to under-desk cable channel | |
| Ambient LED lighting | Touch-controlled warm white LED strip illuminates right side panel junction | |
| Drawer operation | Soft-close full-extension drawers with optional key lock for secure file storage | |
| Cabinet door operation | Soft-close self-latching doors with 110-degree opening angle for supply access | |
| Edge safety design | Rounded soft corners and beveled edges eliminate sharp impact points on all desktop edges | |
| Modesty panel privacy | Fluted front panel blocks direct view of seated user legs from office entrance | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits CEO/manager private office spaces for daily administrative work | |
|---|---|---|
| Corporate leadership workspace | Supports multi-monitor setups, document review and visitor meetings across desk | |
| High-end home office | Suitable for luxury home workspaces for senior professionals or remote executives | |
| Boardroom auxiliary workstation | Can be used as a meeting leader station adjacent to conference areas | |
| Recommended matching chair | Pairs with high-back leather or upholstered executive office chairs with 5-star base | |
| Recommended matching storage | Pairs with matching height file cabinets or display bookcases for coordinated office set |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for desk structure | |
|---|---|---|
| EN 13722:2004 | Furniture strength and durability for office storage units in side cabinet |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and durability standard for office work surfaces |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural safety | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E0 grade requirement for substrates | |
| GB/T 4897.3-2015 | Particleboard specification for furniture structural use, applicable to cabinet components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural safety; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E0 grade requirement for substrates; 3. GB/T 4897.3-2015: Particleboard specification for furniture structural use, applicable to cabinet components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
