Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 2100 x 768 mm | |
|---|---|---|
| Main worktop thickness | 66 mm | |
| Main worktop depth (central writing area) | 1000 mm | |
| Left storage pedestal width | 800 mm | |
| Left storage pedestal depth | 650 mm | |
| Seated knee clearance height | 670 mm | |
| Seated knee clearance width | 1200 mm | |
| Right end support panel thickness | 120 mm | |
| Edge band thickness | 2 mm | |
| Recessed desktop inlay width | 150 mm | |
| Ambient light strip recess height | 20 mm | |
| Corner radius on all exposed edges | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 260 kg | |
|---|---|---|
| Desktop static uniform load capacity | 300 kg | |
| Drawer slide static load rating per drawer | 45 kg | |
| Drawer slide durability cycles | 50000 | |
| Cabinet hinge durability cycles | 80000 | |
| Cable grommet usable diameter | 80 mm | |
| High-gloss surface abrasion resistance | 2000 cycles | |
| Recommended maximum user weight for seating | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E0-grade MDF core | |
|---|---|---|
| Worktop surface finish | Smoked walnut wood veneer | |
| Cabinet panel finish | High-gloss dark grey polyurethane lacquer | |
| Edge banding | Solid wood veneer edging, painted to match worktop | |
| Support structure | Reinforced steel internal frame with panel cladding | |
| Cabinet hardware | Zinc-alloy soft-close hinges and three-section ball-bearing slides | |
| Ambient lighting | 24V LED strip with diffused cover, recessed at pedestal base | |
| Recessed desktop inlay | Matte black leatherette writing surface | |
| Lock system | Concealed fingerprint/password drawer lock | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Left return pedestal with 3 soft-close drawers and 1 door compartment | |
|---|---|---|
| Cable management | Internal wire channels in pedestal and 80mm flip-top cable grommet on worktop | |
| Ambient lighting operation | Touch-controlled dimmable LED base strip with warm white output | |
| Drawer operation | Full-extension soft-close drawer slides with automatic damping in final 50mm travel | |
| Door operation | Soft-close concealed hinges with 110-degree opening angle | |
| Security feature | Concealed biometric/password lock for top pedestal drawer for document security | |
| Power access option | Flip-up integrated power module with AC sockets, USB-A/USB-C charging ports | |
| Surface maintenance | Stain-resistant non-porous high-gloss finish cleanable with mild detergent | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for CEO, director or senior manager private office use, professional upscale appearance | |
|---|---|---|
| High-end meeting space | Can be used in boardroom support areas or executive meeting rooms for formal document work | |
| Home office (luxury) | Suitable for high-end residential home office spaces, minimalist aesthetic matches modern interior design | |
| Single user operation | Designed for single seated user with dedicated central knee clearance and left-side storage access | |
| Configuration flexibility | Can be specified with left or right return orientation to match office room layout | |
| Matching furniture set | Pairs with matching executive leather chair, side credenza and bookcase for complete office suite |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to work surface load tests | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and ergonomic requirements, applicable to knee clearance verification | |
| EN 13722:2004 | Furniture strength and durability for storage units, applicable to pedestal drawer testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard, applicable to static load and stability tests | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units safety and performance standard, applicable to drawer slide cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural stability and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E0 grade emission ≤0.05mg/m³ required | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to structural panel substrates | |
| GB/T 1951.2-2013 | Furniture structural strength test for tables, applicable to desk load rating verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural stability and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E0 grade emission ≤0.05mg/m³ required; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to structural panel substrates; 4. GB/T 1951.2-2013: Furniture structural strength test for tables, applicable to desk load rating verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
