Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 3200 x 2250 x 760 mm | |
|---|---|---|
| Main work surface dimensions | 2000 x 1050 mm | |
| Right return credenza dimensions | 1200 x 1200 x 600 mm | |
| Desktop thickness | 50 mm | |
| Knee clearance height | 630 mm | |
| Knee clearance width | 1600 mm | |
| Integrated writing pad dimensions | 800 x 400 mm | |
| Support pillar cross-section | 120 x 120 mm | |
| Modesty panel height | 550 mm | |
| Solid wood edge banding thickness | 2 mm | |
| Cable grommet diameter | 60 mm | |
| Return credenza storage interior depth | 380 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Finish abrasion resistance | 2000 revolutions | |
| Product net weight | 180 kg | |
| Recommended user weight capacity | 150 kg | |
| Warranty period | 5 years | |
| Available color finish count | 5 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E1 grade high-density fiberboard | |
|---|---|---|
| Surface veneer | 0.6 mm mahogany wood veneer | |
| Support pillars and framing | Solid hardwood frame | |
| Edge trim | Solid wood molded edge banding | |
| Surface finish | High-gloss polyurethane lacquer | |
| Modesty and cabinet panels | MDF core with matching wood veneer | |
| Hardware components | Rust-proof zinc-plated steel | |
| Inset writing pad | Black smooth faux leather surface | |
| Foot levelers | Nylon and steel adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Enclosed cabinet compartments and drawers in main base and return | |
|---|---|---|
| Cable management | Concealed cable routing from grommets to under-desk space | |
| Adjustable leveling | 15 mm height adjustment on foot glides | |
| Drawer locking mechanism | Centralized key lock for main pedestal drawers | |
| Return credenza use | Flat side surface for display and additional storage | |
| Knee well design | Unobstructed open space under main desktop | |
| Modesty panel coverage | Full front panel covering under-desk area | |
| Surface resistance properties | Stain, heat, acid and alkali resistant lacquer | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 2100 x 1150 x 350 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Formal high-level management workspace, paired with executive chair and matching storage cabinetry | |
|---|---|---|
| Corporate boardroom annex | Secondary workspace for senior leadership meeting preparation and document review | |
| High-end home office | Premium dedicated study space for senior professionals and business owners | |
| Government official office | Formal official workspace matching traditional wood furniture style and functional requirements | |
| Recommended pairing | Matched with high-back leather executive chair and full-height wood bookcase for coordinated suite layout | |
| Use case suitability | Supports daily administrative work, document signing, and small in-office meeting hosting |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance verification | |
|---|---|---|
| EN 13722:2004 | Furniture assessment of surface resistance, applicable to lacquer finish durability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and dimensions | |
|---|---|---|
| GB/T 11718-2009 | Medium density fiberboard standard, applicable to substrate formaldehyde emission and strength | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit, applicable to finished furniture VOC control |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and dimensions; 2. GB/T 11718-2009: Medium density fiberboard standard, applicable to substrate formaldehyde emission and strength; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit, applicable to finished furniture VOC control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
