| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 800 x 760 mm | |
|---|---|---|
| Desktop thickness | 64 mm | |
| Knee clearance width | 1000 mm | |
| Knee clearance height | 700 mm | |
| Pedestal depth | 600 mm | |
| Edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Plinth base height | 50 mm | |
| Center modesty panel height | 600 mm | |
| Desktop overhang depth | 50 mm | |
| Pedestal corner radius | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 158 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Desk net weight reference | 115 kg | |
| Recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | 18mm thick E0-grade engineered wood particleboard | |
|---|---|---|
| Desktop finish | Light oak matte melamine laminate, scratch-resistant and stain-resistant | |
| Center modesty panel | MDF substrate with vertical fluted off-white matte paint finish | |
| Edge trim | 2mm thick off-white PVC edge banding with rounded profile | |
| Pedestal case | 15mm thick engineered wood with matching light oak melamine finish | |
| Drawer hardware | Cold-rolled steel ball-bearing full-extension slides | |
| Door hinges | Zinc-alloy soft-close concealed hinges | |
| Cable grommet | ABS plastic with brush insert for cable pass-through | |
| Plinth base | 1.2mm thick steel with off-white powder-coated finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Two side pedestals with combination of file drawers and supply storage compartments | |
|---|---|---|
| Cable management | Desktop cable grommet with under-desk cable routing tray to hide wiring | |
| Modesty privacy panel | Full-height fluted center panel blocks leg visibility from front | |
| Soft-close drawer operation | Drawers close silently without slamming via integrated damper hardware | |
| Fixed working height | 760mm desktop height optimized for standard seated office task chairs | |
| Rounded edge protection | All desktop and pedestal corners have soft radii to reduce impact injury | |
| Leveling adjustment | Adjustable feet on plinth base to compensate for uneven floor surfaces | |
| Locking storage option | Pedestal drawers support optional central locking for document security | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for 20sqm private management offices with professional aesthetic | |
|---|---|---|
| Home office workspace | Ideal for dedicated home offices requiring integrated storage and cable management | |
| Conference meeting small room | Usable as a small meeting table for 3person discussion sessions | |
| Commercial office project fitting | Suitable for bulk procurement for corporate office renovation projects | |
| Seated task work configuration | Optimized for use with standard adjustable office task chairs at 760mm working height | |
| Cable-dependent tech setup | Supports desktop computers, monitors, and charging devices via integrated cable routing |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables: dimensional and safety requirements for fixed-height desks | |
|---|---|---|
| EN 15372:2016 | Durability and strength requirements for non-domestic office storage furniture | |
| EN 13986:2004+A1:2015 | Wood-based panel performance requirements for furniture construction |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products: static load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage components including drawers and hinges |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desk structural stability | |
|---|---|---|
| GB/T 18580-2017 | Formaldehyde emission limits for wood-based panels, required for interior office use | |
| GB/T 4897-2015 | Performance requirements for particleboard used in furniture case construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desk structural stability; 2. GB/T 18580-2017: Formaldehyde emission limits for wood-based panels, required for interior office use; 3. GB/T 4897-2015: Performance requirements for particleboard used in furniture case construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
