| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 1800 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static uniform load capacity | 150 kg | |
|---|---|---|
| drawer slide cycle durability | 50000 open/close cycles | |
| cabinet door hinge cycle durability | 80000 open/close cycles | |
| surface abrasion resistance rating | 2000 cycles | |
| structural stability lateral load rating | 40 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| main desktop substrate | 25mm thick E1 grade high-density particleboard core | |
|---|---|---|
| desktop finish | Walnut woodgrain thermally fused melamine laminate | |
| vertical base panels | 18mm thick MDF with vertical fluted routing and dark taupe matte lacquer finish | |
| edge banding | 2mm thick impact-resistant ABS matching woodgrain and dark panel finishes | |
| integrated work mat | 3mm thick black matte PU leather inset with stitched edge | |
| drawer slides | Cold-rolled steel full-extension ball-bearing slides with zinc plating | |
| cabinet hinges | Nickel-plated cold-rolled steel soft-close concealed hinges | |
| base plinth glides | High-density polyethylene adjustable leveling glides | |
| cable management components | ABS plastic grommet with brush insert and steel under-desk cable tray | |
| internal drawer components | 12mm thick MDF drawer boxes with melamine lining | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| cable management system | 80mm diameter brush grommet routes cords from desktop to under-desk tray, accommodating up to 6 power/data cords | |
|---|---|---|
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
