Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3200 x 2200 x 760 mm | |
|---|---|---|
| Main worktop thickness | 50 mm | |
| Rounded desktop corner radius | 50 mm | |
| Seated knee clearance height | 660 mm | |
| Side return worktop depth | 900 mm | |
| Storage base plinth height | 50 mm | |
| Front decorative panel width | 2400 mm | |
| Cable grommet diameter | 80 mm | |
| Desktop edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide dynamic load rating | 45 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Door hinge open/close cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Product net weight | 280 kg | |
| Recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E1 grade MDF core | |
|---|---|---|
| Worktop facing | Walnut wood veneer with matte UV-cured finish | |
| Front decorative trim | Gold-toned brushed aluminum alloy | |
| Front inset panel | Textured embossed laminate with geometric pattern | |
| Storage cabinet body | E1 grade particleboard with walnut melamine laminate | |
| Drawer slides | Cold-rolled steel three-section soft-close full extension slides | |
| Base leveling glides | Nylon-padded adjustable steel glides | |
| Edge banding | 2mm thick PVC edge matching walnut finish | |
| Cable grommet | ABS plastic with brushed metal cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | 80mm diameter desktop grommet with under-desk routing channel | |
|---|---|---|
| Storage configuration | Full-width floor-length enclosed base with file drawers and storage compartments | |
| Drawer operation | Soft-close three-section slide drawers with 450mm full extension travel | |
| Work surface layout | L-shaped configuration with dedicated main task zone and extended side return | |
| Leveling adjustment | Adjustable base glides with 15mm vertical travel for uneven office floors | |
| Edge safety design | Rounded 50mm radius corners on all desktop edges to reduce impact injury | |
| Drawer locking function | Central lock system securing all storage drawers for document security | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Largest shipping carton dimensions | 2450 x 1050 x 220 mm | |
|---|---|---|
| Total packaged gross weight | 320 kg | |
| Total packaged volume | 1.6 CBM | |
| Required assembly time | 120 minutes | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for CEO, director, or senior manager private workspaces for professional prestige | |
|---|---|---|
| High-end corporate headquarters | Designed for premium grade-A office buildings to match luxury interior fit-outs | |
| Single user seated work | Configured for full-time individual administrative and decision-making work tasks | |
| Meeting side return use | Extended side worktop accommodates 3 guest seats for small impromptu office meetings | |
| Document storage integration | Full-width base provides on-hand filing for frequently accessed office documents and supplies | |
| Matching office suite configuration | Pairs with matching high-back executive leather chairs and visitor seating sets |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance acceptance | |
|---|---|---|
| EN 13722:2004 | Furniture storage units strength and durability requirements, applicable to cabinet base checks |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, mandatory E1 grade acceptance requirement | |
| GB/T 4893.8-2013 | Surface abrasion resistance test method for furniture finishes, applicable to desktop durability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural acceptance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, mandatory E1 grade acceptance requirement; 3. GB/T 4893.8-2013: Surface abrasion resistance test method for furniture finishes, applicable to desktop durability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
