Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 460 mm | |
|---|---|---|
| Upper cantilever top dimensions | 1350 x 600 x 35 mm | |
| Lower base top dimensions | 1050 x 600 x 35 mm | |
| Vertical clearance between tiers | 120 mm | |
| Base plinth height | 50 mm | |
| Perforated metal accent panel size | 120 x 60 mm | |
| Bronze trim thickness | 2 mm | |
| Upper top cantilever overhang (right end) | 250 mm | |
| Tabletop panel thickness | 15 mm | |
| Base enclosure panel thickness | 15 mm | |
| Floor clearance under base plinth | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Upper tabletop static distributed load | 75 kg | |
|---|---|---|
| Lower base top static distributed load | 80 kg | |
| Product net weight | 40 kg | |
| LED strip rated operational lifespan | 30000 hours | |
| Surface scratch resistance rating | 2B | |
| Adjustable foot pad load capacity | 80 kg per pad | |
| Recommended maximum number of users | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upper tabletop core | 15mm thick MDF with dark walnut wood veneer finish | |
|---|---|---|
| Lower top and base enclosure | 15mm thick MDF with dark charcoal high-gloss lacquer finish | |
| Edge and plinth trim | Powder-coated bronze-finished steel, 2mm thickness | |
| Left end decorative panel | Perforated steel with dark bronze powder coat, diamond lattice pattern | |
| Underbase lighting | SMD 2835 warm white LED strip, aluminum channel housing | |
| Internal connecting hardware | Zinc-plated steel cam lock connectors and wood screws | |
| Floor protection pads | Polyethylene non-slip adjustable foot pads | |
| Surface coating | UV-cured high-gloss clear topcoat, 0.15mm dry film thickness | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Ambient underbase LED lighting | Integrated warm white LED strips along all base plinths, controlled by inline touch switch | |
|---|---|---|
| Two-tier stepped surface layout | Offset cantilever upper top creates separate display and serving zones without blocking lower surface access | |
| Floor level adjustment | 4 adjustable PE foot pads to stabilize table on uneven floor surfaces | |
| Surface maintenance | Waterproof and stain-resistant high-gloss finish allows wipe-clean care with soft damp cloth | |
| Enclosed base structure | Fully enclosed block base hides internal hardware and cable routing for LED power supply | |
| Decorative perforated vent panel | Left end recessed perforated panel allows passive ventilation for internal LED power supply | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary placement | Centered in front of 3-seat or L-shaped sofas in contemporary residential living rooms | |
|---|---|---|
| Complementary design schemes | Pairs with modern minimalist, luxury contemporary or dark-toned interior palettes | |
| Functional use cases | Serving beverages, displaying decorative objects, holding reading materials and remote controls | |
| Commercial hospitality use | Suitable for upscale hotel lounge areas, private club seating zones and high-end apartment common areas | |
| Lighting function use | Provides soft ambient floor glow for low-light evening entertaining without overhead lighting |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic living room tables | |
|---|---|---|
| EN 62471:2008 | Photobiological safety for LED light sources used in furniture installations | |
| EN 13722:2004 | Performance requirements for melamine faced furniture panels used in table tops |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural performance verification | |
|---|---|---|
| GB/T 4893.4-2013 | Surface wear resistance test for furniture coatings, applicable for high-gloss topcoat durability | |
| GB 7000.204-2008 | Safety requirements for built-in furniture LED lighting systems, applicable for underbase LED components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural performance verification; 2. GB/T 4893.4-2013: Surface wear resistance test for furniture coatings, applicable for high-gloss topcoat durability; 3. GB 7000.204-2008: Safety requirements for built-in furniture LED lighting systems, applicable for underbase LED components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
