Automatic mm / inch conversion · Core engineering specifications
| Overall L-shaped dimensions | 2400 x 2100 x 760 mm | |
|---|---|---|
| Main desktop thickness | 50 mm | |
| Side return width | 1200 mm | |
| Main desktop depth | 1100 mm | |
| Seated knee clearance height | 650 mm | |
| Knee clearance width | 1400 mm | |
| Modesty panel height | 680 mm | |
| Desk pad insert size | 1200 x 600 mm | |
| Pedestal storage height | 650 mm | |
| Edge banding thickness | 2 mm | |
| Decorative column corner width | 120 mm | |
| Plinth base height | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Main desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide dynamic load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 80000 cycles | |
| Cable grommet diameter | 60 mm | |
| Net product weight | 185 kg | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | High-density fiberboard (HDF) substrate | |
|---|---|---|
| Desktop surface | 0.6mm natural wood veneer with PU gloss paint finish | |
| Decorative trim and plinth | Solid hardwood molded accents | |
| Desk pad insert | Black faux leather with non-slip backing | |
| Structural support frame | 40x40mm square hardwood internal framing | |
| Drawer and cabinet panels | 18mm thick HDF with matching veneer finish | |
| Hardware components | Zinc alloy chrome-finished drawer pulls and hinges | |
| Cable grommets | ABS plastic matching wood finish | |
| Adjustable foot glides | Nylon with metal threaded stems | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | 4 full-extension drawers + 2 cabinet compartments in pedestal and return | |
|---|---|---|
| Cable management | 2 desk-top cable grommets with under-desk cable tray | |
| Drawer locking mechanism | Central lock securing all pedestal drawers | |
| Privacy modesty panel | Full-height solid front panel blocking under-desk view | |
| Leveling adjustment | 15mm vertical adjustment via foot glides | |
| File storage compatibility | One drawer sized for legal/letter hanging file folders | |
| Surface finish performance | Stain and scald resistant PU coating | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Designed for CEO/president private office spaces, paired with high-back leather executive chair | |
|---|---|---|
| Traditional formal office decor | Matches classical red-brown wood furniture sets including bookcases and leather office seating | |
| Seated desktop work | Optimized for 760mm work height, suitable for writing, computer work and document review | |
| High-security document storage | Locking pedestal storage supports confidential executive document organization | |
| Large open office layouts | Recommended for spacious executive suites minimum 16 sqm floor area | |
| Matching furniture sets | Pairs with matching red-brown wood bookcases, guest sofas and conference seating |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural load testing | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units performance requirements, applicable for cabinet/drawer durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for static load and cycle testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for drawer and hinge durability validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for structural and dimensionalAcceptance inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for structural and dimensionalAcceptance inspection; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
