Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk + right return) | 2800 x 2200 x 760 mm | |
|---|---|---|
| Main work surface depth | 1200 mm | |
| Right return surface dimensions | 1200 x 600 mm | |
| Tabletop total thickness | 90 mm | |
| Central seated knee clearance width | 800 mm | |
| Knee clearance height under work surface | 650 mm | |
| Inset black leather writing pad dimensions | 1800 x 400 mm | |
| Drawer panel thickness | 18 mm | |
| Drawer base panel thickness | 9 mm | |
| Decorative fretwork panel size per side | 400 x 400 mm | |
| Edge band thickness on tabletop | 2 mm | |
| Natural wood veneer thickness | 0.8 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total static load capacity of work surface | 300 kg | |
|---|---|---|
| Drawer slide operational cycle rating | 80000 cycles | |
| Hinge operational cycle rating (for cabinet doors) | 100000 cycles | |
| Surface abrasion resistance | 5000 revolutions no visible scratch | |
| Wood moisture content | 10% | |
| Cable grommet internal diameter | 80 mm | |
| Standard warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Core substrate panels | E0 grade medium density fiberboard, formaldehyde emission 0.025 mg/m³ | |
|---|---|---|
| Surface wood veneer | 0.8mm thick natural hardwood veneer, redwood stain finish | |
| Top coating | 7-coat 3-layer water-based polyurethane paint, gloss level 85 GU | |
| Central writing pad | Black top-grain leather inset, 2mm thick, stitched edge | |
| Drawer front panels | Textured black matte laminate surface, framed with solid wood trim | |
| Structural joinery | Traditional mortise and tenon joints, fit tolerance ±0.08mm | |
| Drawer hardware | Cold-rolled steel soft-close slides, rust-resistant 10-level salt spray rating | |
| Decorative panels | Solid wood carved traditional Chinese fretwork, matte black inlay | |
| Desk base support frame | Solid hardwood frame, 40mm cross-section structural members | |
| Edge trim | Solid wood matching veneer grain, raised profile edge on tabletop perimeter | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Drawer storage configuration | Four central soft-close drawers (two upper, two lower) for office supply storage | |
|---|---|---|
| Cable management system | Hidden cable grommets at desk corners with under-detached cable tray for wire organization | |
| Right return work surface | Fixed extended side surface for guest seating, printer placement or auxiliary work | |
| Side cabinet storage | Left and right front decorative panels enclose concealed storage compartments for document storage | |
| Writing surface function | Inset leather pad reduces writing indentation and provides smooth surface for document signing | |
| Surface maintenance feature | Stain-resistant polyurethane finish allows cleaning with mild detergent without damage | |
| Leveling adjustment | Adjustable floor glides on base feet to compensate for uneven office flooring | |
| Assembly structure | Knock-down construction with mortise and tenon reinforced joints for on-site assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office space | Suited for senior management/executive private offices, matches traditional formal office design aesthetic | |
|---|---|---|
| Large-scale corporate meeting spaces for leadership | Appropriate for executive meeting rooms requiring premium traditional office furniture | |
| High-end traditional Chinese style commercial spaces | Fits spaces with fretwork, redwood wood and classic oriental design themes | |
| Paired with matching carved leather executive chairs | Designed for use with matching tufted leather executive seating visible in reference imagery | |
| Office document and supply storage use | Integrated drawers and cabinets support long-term document and office supply organization | |
| Guest reception in executive work areas | Right return surface accommodates guest seating for in-office meetings and document review |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable to ergonomic work surface and clearance verification | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables - Part 2: Mechanical safety requirements, applicable to structural stability testing | |
| EN 13722:2004 | Furniture - Work tables and desks - Test methods for surface finish durability, applicable to abrasion resistance testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Furnishings - Desk Products, applicable to structural load and durability performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units for Office Environments, applicable to integrated drawer and cabinet performance testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural quality inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture, applicable to VOC and formaldehyde testing | |
| GB/T 4897.3-2003 | Particleboard and fiberboard for furniture use, applicable to core substrate performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality inspection; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture, applicable to VOC and formaldehyde testing; 3. GB/T 4897.3-2003: Particleboard and fiberboard for furniture use, applicable to core substrate performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
