Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk + left return) | 2400 x 2000 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 185 kg | |
| Seating capacity for work use | 1 person | |
| Surface abrasion resistance | 2000 cycles | |
| Ambient light strip operating lifespan | 30000 hours | |
| Recommended maximum user weight for desk edge loading | 100 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop surface | 25mm thick melamine-faced MDF with woodgrain finish, rounded soft edges | |
|---|---|---|
| Left return cabinet body | 38mm thick engineered wood with matte light taupe polyurethane coating | |
| Corner support columns | 25mm thick engineered wood with matching dark grey woodgrain melamine finish | |
| Central drawer front panel | 18mm thick fluted engineered wood with matte light taupe finish, integrated linear LED strip along top edge | |
| Embedded cable grommet | Brushed ABS plastic with sliding cover | |
| Integrated ambient lighting | Low-voltage 3000K warm white LED strip with aluminum housing | |
| Drawer sliding hardware | Cold-rolled steel three-section full-extension soft-close slides | |
| Desk base levelers | Nylon adjustable height glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management grommet | Sliding cover oval port routes power and data cables from work surface to under-desk cavity | |
|---|---|---|
| Full-width under-desk storage drawer | Single soft-close drawer runs length of main desk, operates via push-to-open mechanism with no visible handles | |
| Integrated ambient lighting | Touch-activated warm white LED strip illuminates floor area behind drawer front, with 3 brightness levels | |
| Dual work zone layout | Main front work zone for computer work, left return zone for document staging or meeting use | |
| Edge comfort design | Fully rounded worktop edges eliminate sharp contact points during extended seated use | |
| Adjustable base leveling | Hidden glides at each support base allow 15mm height adjustment to compensate for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary use for senior management, with sufficient surface area for computing, document review and small visitor meetings | |
|---|---|---|
| High-end corporate boardroom side workstation | Placed adjacent to conference tables for meeting materials preparation and note-taking | |
| Executive home office | Suitable for residential workspaces requiring luxury aesthetic and large functional work surface | |
| Corporate leadership reception area | Used as primary workspace for reception managers handling visitor check-in and administrative tasks | |
| Recommended matching seating | Paired with high-back executive ergonomic chairs with 520 mm adjustable seat height to align with 750mm worktop height |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance validation | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and clearance requirements, applicable to ergonomic fit checks | |
| EN 13722:2004 | Office furniture storage units strength and durability requirements, applicable to drawer performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to load capacity, durability and stability testing for commercial use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural strength and finish quality checks | |
|---|---|---|
| GB/T 3327-2016 | Test methods for stability of office furniture, applicable to desk overturn risk verification | |
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, applicable to indoor air quality acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural strength and finish quality checks; 2. GB/T 3327-2016: Test methods for stability of office furniture, applicable to desk overturn risk verification; 3. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, applicable to indoor air quality acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
