Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total assembled product weight | 185 kg | |
|---|---|---|
| Main work surface static load capacity | 150 kg | |
| Recommended maximum user weight for paired task chair | 150 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Edge impact resistance | 45 N | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | 25mm thick medium-density fiberboard | |
|---|---|---|
| Work surface finish | 0.6mm thick red brown hardwood veneer with high-gloss polyurethane clear coat | |
| Vertical support panels | 18mm thick MDF with matching wood veneer laminate | |
| Decorative accent inserts | 3mm thick matte black rigid PVC panel | |
| Edge trim | Solid hardwood molding with mitered corner joints | |
| Storage drawer slides | Cold-rolled steel 3/4 extension ball bearing slides | |
| Desk base glides | Nylon height-adjustable leveling glides | |
| Cable grommets | Brushed silver ABS plastic with removable cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Fixed L-shaped configuration | Permanently attached right-side return provides additional auxiliary work surface and storage, no reconfiguration | |
|---|---|---|
| Cable management system | Two surface grommets and one rear return cabinet oval cable port route power and data cables from desk top to underfloor | |
| Integrated drawer storage | Left pedestal holds 5 utility drawers for office supplies and document storage, mounted on smooth steel slides | |
| Leveling adjustment | Corner nylon glides adjust 10mm vertically to compensate for uneven carpet or hard flooring | |
| Central modesty panel | Full-height solid wood panel between support pedestals blocks under-desk visibility from front-facing positions | |
| Inset writing mat | Recessed black leather-look desk mat provides non-slip writing surface centered at user position | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits 20sqm senior management offices as primary work surface with dedicated visitor seating zone | |
|---|---|---|
| Corporate boardroom ancillary workspace | Serves as a presentation or document preparation station adjacent to conference meeting tables | |
| Government institutional office | Matches formal dark wood aesthetic requirements for public sector leadership workspaces | |
| Paired seating configuration | Designed for use with high-back leather executive chairs and 3-seat visitor seating sets for guest meetings | |
| Matching storage configuration | Pairs with matching 4-door wooden filing cabinets for centralized document storage coordination |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for office work table dimensional, strength and stability requirements for commercial use | |
|---|---|---|
| EN 13986:2004+A1:2015 | Applicable for wood-based panel formaldehyde emission requirements, Class E1 ≤0.124mg/m3 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture, including dimensional tolerance and structural stability | |
|---|---|---|
| GB/T 4897.3-2018 | Applicable for MDF substrate formaldehyde emission limits, requiring E1 grade ≤0.124mg/m3 emission | |
| GB/T 17657-2013 | Applicable for test methods for surface finish durability, including abrasion and impact resistance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture, including dimensional tolerance and structural stability; 2. GB/T 4897.3-2018: Applicable for MDF substrate formaldehyde emission limits, requiring E1 grade ≤0.124mg/m3 emission; 3. GB/T 17657-2013: Applicable for test methods for surface finish durability, including abrasion and impact resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
