Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1000 × 760 mm | |
|---|---|---|
| Worksurface thickness | 36 mm | |
| Edge banding thickness | 2 mm | |
| Seating-side overhang | 127 mm | |
| Central knee opening width | 800 mm | |
| Knee clearance height under worktop | 650 mm | |
| Pedestal base height | 720 mm | |
| Gold slat accent trim height | 80 mm | |
| Cable grommet diameter | 80 mm | |
| Corner radius of worktop edges | 30 mm | |
| Drawer front panel height | 150 mm | |
| Modesty panel thickness | 18 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worksurface static load capacity | 300 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 100000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Seating user capacity | 1 | |
| Product net weight reference | 185 kg | |
| Structural warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface core | High-density MDF substrate with veneer or laminate finish | |
|---|---|---|
| Worksurface finish | Scratch-resistant matte dark wood-tone lacquer | |
| Pedestal cabinet body | E1-grade engineered wood composite panel | |
| Decorative lower trim | Gold-toned brushed aluminum alloy slats | |
| Edge banding | 2mm thick impact-resistant PVC edging | |
| Drawer hardware | Cold-rolled steel three-section ball-bearing slides | |
| Cabinet hinges | Nickel-plated steel soft-close concealed hinges | |
| Leveling glides | Nylon-padded adjustable steel glides at base corners | |
| Modesty panel | 18mm thick matching beige engineered wood panel | |
| Cable grommets | ABS plastic brushed finish desk grommets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated storage pedestals | Dual side storage units with file drawers and supply compartments | |
|---|---|---|
| Cable management system | Two surface grommets connected to under-desk cable channel | |
| Soft-close drawer mechanism | Drawers close silently without slamming via damped slide hardware | |
| Adjustable leveling glides | 15mm vertical adjustment range at base feet | |
| Rounded edge protection | Bullnose rounded front and side worktop edges | |
| Full-length modesty panel | Solid panel covers knee opening from front view | |
| Lockable storage option | Central locking secures all drawers with a single key | |
| Scratch-resistant easy-clean surface | Non-porous lacquer finish wipes clean with standard office cleaners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Primary use for CEO, director or senior manager dedicated workspace | |
|---|---|---|
| Home executive office | Suitable for high-end residential workspaces requiring formal professional styling | |
| Boardroom ancillary workspace | Placed adjacent to meeting rooms for executive preparation or document review | |
| Paired furniture configuration | Matches with high-back leather executive chairs and matching wall storage credenzas | |
| Cable management suitability | Designed for laptop, desktop monitor, phone and office device connectivity | |
| Commercial office project use | Specified for high-end corporate fit-outs requiring durable luxury executive furniture |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial work surfaces | |
|---|---|---|
| EN 13722:2004 | Furniture storage units strength and durability requirements for desk pedestals | |
| EN 71-3:2019+A1:2021 | Migration of certain elements applicable to all furniture surface coatings |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard covering load, stability and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated desk pedestals and drawers |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural stability | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard specification for furniture-grade substrate used in cabinet panels | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for desk static load and durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural stability; 2. GB/T 4897.3-2015: Particleboard specification for furniture-grade substrate used in cabinet panels; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use; 4. GB/T 10357.1-2013: Furniture mechanical performance test for desk static load and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
