PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3200 × 2200 × 750 mm
Overall desk footprint	3200 x 2200 x 750 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Desktop distributed static load	120 kg
Pedestal cabinet top load	60 kg per side
Drawer slide load per drawer	35 kg
Internal adjustable shelf load	30 kg per shelf
Recommended user size	1 person primary, 4 visitors seated across front
Chair recommended weight capacity	150 kg
Desk product net weight	260 kg
LED service life	30000 hours
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop	Wood-based panel with warm wood veneer or melamine woodgrain finish and sealed edge banding
Support bases	Painted MDF or engineered wood with matte warm-gray finish and rounded exposed corners
Central modesty panel	Wood-based panel with warm woodgrain laminate and horizontal trim reveal
Rear cabinet doors	Flat woodgrain engineered-wood doors with matching edge profile and concealed hinges
Upper display front	Smoked-tempered glass front with black frame and horizontal shelf dividers
Internal cabinet structure	18 mm engineered-wood carcass with 25 mm adjustable shelves and metal shelf supports

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Storage layout	Two enclosed side support cabinets, central privacy panel and full rear credenza with side doors and open display storage
Cable management	80 mm desktop grommet with under-desk cable channel for laptop, power and data routing
Lighting system	Warm-white LED strips illuminate both vertical credenza pilasters and the central display backsplash
Display function	Central glass-front upper bay provides two shelf levels for awards, books and decorative objects

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Total packed volume	3.20 cbm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Executive office	Suits director, partner or executive rooms where a 3200 mm desk and rear presentation storage create a formal work-and-meeting zone
Commercial procurement package	Pair with a high-back executive chair, task lighting, power/data outlet modules and anti-tip wall anchoring for the credenza

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1 office desk safety	Use for desk dimensions, safety, strength and durability requirements in commercial offices
EN 527-2 office desk mechanical tests	Use for strength, durability and stability acceptance testing of the work surface
EN 16121 office storage safety	Use for strength, durability and stability of the credenza, doors and shelves
EN 16122 office storage test methods	Use as the mechanical test method for cabinet shelves, doors and attachments

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5 desk and table products	Applicable standards and test results require confirmation
ANSI/BIFMA X5.9 storage units	Recommended for cabinet shelf, door, lock and stability performance verification
ANSI/BIFMA X5.1 office chairs	Apply separately when purchasing the visible executive chair, including static, impact and durability tests

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324 dimensional and structural suitability	Applies to wooden office furniture dimensions, tolerances, stability and workmanship inspection
GB/T 3325 metal hardware suitability	Applies where metal furniture components, hinges, slides and connector parts are used
GB 18580 formaldehyde emission	Use as the acceptance limit for engineered-wood panels in the desk and credenza
GB/T 10357.6 furniture stability	Recommended for desk and storage-wall static stability verification

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324 dimensional and structural suitability: Applies to wooden office furniture dimensions, tolerances, stability and workmanship inspection;
2. GB/T 3325 metal hardware suitability: Applies where metal furniture components, hinges, slides and connector parts are used;
3. GB 18580 formaldehyde emission: Use as the acceptance limit for engineered-wood panels in the desk and credenza;
4. GB/T 10357.6 furniture stability: Recommended for desk and storage-wall static stability verification;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · EXD-LED-3200

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · EXD-LED-3200

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · EXD-LED-3200Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Executive Office Desk with Integrated Storage Credenza, model EXD-LED-3200, presents a modern executive workplace as a coordinated L-shaped workstation with a full rear storage and display credenza. Unbranded by supply designation, the suite balances warm woodgrain work surfaces with matte warm-gray support bases, black-framed smoked tempered glass, and metal hardware for a formal, composed office aesthetic. The overall footprint measures 3200 x 2200 x 750 mm, with a 50 mm finished top and 680 mm high by 900 mm wide knee clearance at the main seat. The support section is 80 mm with a 2 mm metal wall, and exposed base corners are rounded. Visually, the wood-based desktop uses warm veneer or melamine woodgrain with sealed edge banding, while the central modesty panel carries matching laminate and a horizontal trim reveal. Two enclosed side support cabinets anchor the desk, and the rear credenza combines side doors, central open display storage, horizontal shelf dividers, vertical pilasters, and a glass-front upper bay with two shelf levels for awards, books, and decorative objects. Warm-white LED strips illuminate both credenza pilasters and the central display backsplash. Construction uses an 18 mm engineered-wood cabinet carcass, 25 mm adjustable shelves with metal supports, flat woodgrain engineered-wood rear doors with matching edge profiles and concealed hinges, and painted MDF or engineered wood bases. Functional capacity is rated at 120 kg distributed static load on the desktop, 60 kg on each pedestal cabinet top, 35 kg per drawer slide, and 30 kg per adjustable shelf. An 80 mm desktop grommet connects to an under-desk cable channel with a 120 mm deep tray, supporting laptop, power, and data routing. The layout serves one primary user and four visitors seated across the front, making it suitable for director, partner, or executive offices that combine focused work with informal meetings and presentation storage. The desk net weight is 260 kg. Procurement planning should note the stated packed volume of 3.20 cbm, reference packaging of one set in two cartons, and a 40-minute assembly time; separate logistics data also list 180 kg packaged gross weight in four cartons and 1 m³ packaging volume, so shipment details should be confirmed at order entry. For a complete executive setup, specify a compatible high-back chair rated for a 150 kg user, task lighting, power and data outlet modules, and professional anti-tip wall anchoring for the credenza.

Executive Office Desk with Integrated Storage Credenza Specifications
