Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 500 x 530 mm | |
|---|---|---|
| Cantilevered upper overhang projection | 150 mm | |
| Stepped top height offset between tiers | 80 mm | |
| Main cabinet body height | 420 mm | |
| Top panel total thickness | 30 mm | |
| Base trim thickness | 20 mm | |
| Side support curved radius | 80 mm | |
| Upper stepped top section width | 1200 mm | |
| Lower fixed top section width | 700 mm | |
| Interior compartment clear height | 350 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 90 kg | |
|---|---|---|
| Maximum supported TV screen size | 85 inch | |
| Unit net weight | 100 kg | |
| LED accent lighting operational lifespan | 30000 hours | |
| Drawer/slide cycle rating | 50000 open/close cycles | |
| Hinge cycle rating for cabinet doors | 80000 open/close cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top panel construction | 18mm E0-grade MDF core with dark walnut wood veneer, matte lacquer seal | |
|---|---|---|
| Main cabinet carcass | 16mm E0-grade MDF with matte dark grey PU lacquer finish | |
| Edge trim details | Solid dark wood edge banding along top perimeter and base | |
| Back panel | 5mm MDF with dark matte laminate backing | |
| Interior shelving | 16mm E0-grade MDF with matching dark laminate finish | |
| Hardware components | Powder-coated steel telescoping drawer glides and soft-close hinges | |
| Accent lighting | Low-voltage LED strip with frosted polycarbonate diffuser, integrated into side support | |
| Base support | Full-width engineered wood base plinth with wood veneer trim | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Stepped dual-level top surface | Tiered surfaces separate primary TV placement from secondary media device staging | |
|---|---|---|
| Integrated side accent lighting | Warm-white LED strip in right side support provides ambient room illumination | |
| Enclosed storage compartments | Concealed cabinet space behind front facade hides media equipment and accessories | |
| Integrated cable management | Rear cutouts route power and AV cables between compartments and wall outlets | |
| Adjustable interior shelves | Removable shelf supports allow height adjustment for AV components of varying sizes | |
| Soft-close door/drawer mechanism | Damping hardware prevents slamming and reduces operational noise | |
| Floor leveler feet | Concealed adjustable feet compensate for uneven floor surfaces for stable placement | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned against main wall to support flat-screen TVs and home media equipment | |
|---|---|---|
| Home theater room installation | Provides concealed storage for AV receivers, gaming consoles and media accessories | |
| Modern luxury apartment common areas | Complements contemporary minimalist interior design schemes with two-tone finish | |
| Boutique hotel lounge areas | Serves as media unit in premium guest suites or public lounge spaces | |
| Open-plan condo entertainment zones | Defines media viewing areas without blocking sightlines across open floor plans |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements and test methods | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic seating and storage units | |
| EN 717-1:2004 | Wood-based panels - Formaldehyde release determination, Class E1 emission limit |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural integrity verification | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 4893.4-2013 | Surface wear resistance test for furniture coatings, applicable for finish durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural integrity verification; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 3. GB/T 4893.4-2013: Surface wear resistance test for furniture coatings, applicable for finish durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
