Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 2600 x 1800 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Main desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide operational cycle rating | 50000 cycles | |
| Cabinet door hinge operational cycle rating | 80000 cycles | |
| Laminate surface horizontal abrasion resistance | 2000 revolutions | |
| Overall structural service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop core and panel substrate | 18mm E1-grade high-density particleboard core, low formaldehyde emission, laminated on all faces | |
|---|---|---|
| Desktop and cabinet exterior finish | Dark matte scratch-resistant melamine laminate, 2mm matching PVC edge banding on all exposed edges | |
| Decorative accent trim | 0.8mm thick champagne gold electroplated iron trim, mounted along desktop edges and cabinet seams | |
| Left side storage cabinet structure | 18mm laminated particleboard carcass, flush-mounted full-extension steel drawer slides, soft-close hinges | |
| Base support plinth | 25mm laminated particleboard perimeter frame, raised 30mm above finished floor for cleaning access | |
| Cable management components | ABS plastic desktop cable grommet with 80mm inner diameter, matching matte black finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable routing function | Dual desktop cable grommets route power, data and monitor cords from desktop to under-desk cable tray, 80mm pass-through diameter | |
|---|---|---|
| Storage organization function | Left side pedestal provides 1 lockable file drawer for letter/legal folders, 2 utility drawers for office supplies, 1 closed cabinet compartment for CPU storage | |
| Privacy screening function | Full-width front modesty panel blocks under-desk knee space view from front office entrance for seated user privacy | |
| Hardware soft-close function | All drawer slides and cabinet hinges include soft-close damping to prevent slamming during daily use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive offices | For CEO, director and senior management use, providing expansive work surface and concealed storage for documents and office equipment | |
|---|---|---|
| Open-plan senior workstations | For team leads and senior specialists, supporting multi-monitor setups, document review and small in-desk meetings |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to dimensional tolerance, finish quality and structural stability acceptance | |
|---|---|---|
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels | Applies to substrate formaldehyde emission limits | |
| GB/T 4897.3-2003 Particleboard for furniture use | Applies to particleboard core physical performance requirements for structural panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to dimensional tolerance, finish quality and structural stability acceptance; 2. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: Applies to substrate formaldehyde emission limits; 3. GB/T 4897.3-2003 Particleboard for furniture use: Applies to particleboard core physical performance requirements for structural panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
