Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3200 × 2400 × 780 mm | |
|---|---|---|
| Main desktop thickness | 75 mm | |
| Raised upper shelf height above main top | 200 mm | |
| Raised upper shelf depth | 350 mm | |
| Central knee well width | 1800 mm | |
| Central knee well minimum height | 630 mm | |
| Pedestal base wall thickness | 50 mm | |
| Edge banding thickness | 2 mm | |
| Desktop surface depth at seating position | 900 mm | |
| Rounded corner radius on base/top | 80 mm | |
| Underside cable tray clearance | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Main desktop static load capacity | 300 kg | |
|---|---|---|
| Drawer slide dynamic load rating (per drawer) | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge open/close cycle rating | 80000 cycles | |
| Net weight (assembled) | 230 kg | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main desktop substrate | 25mm E1-grade high-density fiberboard | |
|---|---|---|
| Main desktop finish | 0.6mm dark brown walnut wood veneer with polyurethane clear coat | |
| Pedestal base substrate | 30mm MDF with semi-gloss light brushed silver paint finish | |
| Edge detailing | Solid wood edge trim with polished radius profile | |
| Pedestal bottom trim | Matching dark brown wood veneer kick plate | |
| Raised upper shelf support | Brushed silver steel support brackets | |
| Internal drawer construction | 18mm MDF with soft-close hardware | |
| Cable management grommets | ABS plastic with brushed silver finish cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed work height design | Fixed 750mm work surface height optimized for executive task chairs | |
|---|---|---|
| Dual pedestal storage | Dual side box pedestals with lockable file and utility drawer storage | |
| Full-width raised upper shelf | Full-width elevated second tier for monitor placement, decor, or document staging | |
| Integrated cable management | Recessed desk grommets and under-surface cable channel to route power/data cables | |
| Soft-close drawer operation | Soft-close full-extension ball-bearing drawer slides with central locking system | |
| Rounded impact-resistant edges | Soft rounded corner design on all base and top edges to reduce impact injury | |
| Central seated knee bay | Open central knee clearance to accommodate ergonomic executive office chairs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Suitable for CEO, president, or senior manager private workspaces | |
|---|---|---|
| High-end corporate headquarters | Designed for premium grade-A office tower executive suites | |
| Single-occupant task work | Configured for one seated user with central knee clearance and dual work tiers | |
| Formal client meeting use | Wide surface accommodates in-desk document review with seated visitors | |
| Matching executive office suite | Coordinates with complementary open storage cabinets and leather executive seating |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable standard for office worktables safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Applicable standard for office furniture storage units performance |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable standard for desk products safety and performance |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden furniture | |
|---|---|---|
| GB/T 3327-2017 | Applicable standard for furniture desks and tables performance testing | |
| GB 18580-2017 | Applicable standard for formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden furniture; 2. GB/T 3327-2017: Applicable standard for furniture desks and tables performance testing; 3. GB 18580-2017: Applicable standard for formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
