Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 2200 x 750 mm | |
|---|---|---|
| main work surface thickness | 50 mm | |
| main desk depth | 1000 mm | |
| right return dimensions | 1200 x 600 x 750 mm | |
| knee clearance height | 600 mm | |
| knee clearance width | 1600 mm | |
| fluted modesty panel dimensions | 1600 x 400 x 20 mm | |
| desktop edge band thickness | 2 mm | |
| base panel thickness | 25 mm | |
| cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 150 kg | |
|---|---|---|
| drawer slide static load rating | 45 kg | |
| drawer slide cycle rating | 50000 cycles | |
| integrated LED strip lifespan | 30000 hours | |
| net product weight | 150 kg | |
| surface scratch resistance | 2000 cycles | |
| surface stain resistance | Grade 4 | |
| leveling glide adjustment range | 15 mm | |
| recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface substrate | E0-grade MDF | |
|---|---|---|
| work surface finish | Matte taupe melamine veneer | |
| base and cabinet panels | E1-grade particle board | |
| modesty panel slats | Solid MDF fluted strips | |
| edge banding | 2 mm ABS material | |
| integrated LED strip | Low-voltage 24V SMD LED | |
| drawer slides | Cold-rolled steel with soft-close mechanism | |
| hardware accents | Matte silver aluminum alloy | |
| leveling glides | Nylon base with metal threaded stem | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| ambient LED lighting | Integrated recessed warm-white strip behind fluted modesty panel, dimmable control | |
|---|---|---|
| cable management system | Desktop grommets connected to under-desk cable tray for power/data routing | |
| right return storage | Lockable filing drawer and CPU storage compartment with soft-close slides | |
| seated ergonomic support | 600 mm high knee clearance for standard executive office chair fit | |
| leveling adjustment | Threaded nylon glides at all base corners to compensate for uneven floors | |
| fixed right-side return | Permanent L-shape configuration with non-reversible side credenza | |
| wireless charging pad | Integrated desktop wireless charging zone on right return surface | |
| modesty panel privacy | Full-height fluted front panel blocks leg visibility from front office approach | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| private executive office | Suitable for C-suite and senior management individual workspaces in corporate headquarters | |
|---|---|---|
| high-end home office | Appropriate for luxury residential workspaces requiring refined, professional design | |
| corporate boardroom ancillary space | Usable as a leader-side work surface adjacent to meeting rooms | |
| recommended pairing | Matches with high-back cream leather executive chairs and fluted tall storage bookshelves | |
| user recommendation | Designed for senior management, directors and business owners requiring spacious, organized work surfaces | |
| layout requirement | Requires minimum 3.5m x 3m office floor space for full L-shape placement and chair clearance | |
| power access requirement | Requires nearby 220V power outlet for integrated LED and charging features |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety and ergonomic requirements, applicable for clearance verification | |
| EN 13722:2004 | Furniture assessment of surface resistance to cold liquids, applicable for stain resistance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance, applicable for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer and cabinet performance, applicable for return storage |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for panel constructionAcceptance | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for desks and tables, applicable for static load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E0/E1 substrate verification | |
| GB/T 4897.3-2003 | Specification for particle board used in furniture, applicable for structural panel quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for panel constructionAcceptance; 2. GB/T 3327-2016: Performance test methods for desks and tables, applicable for static load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E0/E1 substrate verification; 4. GB/T 4897.3-2003: Specification for particle board used in furniture, applicable for structural panel quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
